SPROCKET 1.3/4" DUPLEX

Code: ITP134Z16D
€358.60
VAT excluded: €293.93
Size : Z 16
In stock 2 pieces in stock Ships in 24/48 hours

Description

Double Pinion for Roller Chain, 1 3/4 Inch Pitch - Item No. ITP134D00


The SIT double pinion with a pitch of 1 3/4 inches has two rows of teeth and works with double roller chains, that is, chains with two rows of rollers. Reference standards: DIN 8187 and ISO/R 606. For the 1 3/4 inch pitch the manufacturer's ISO range provides chain 28B-2, 1 3/4 x 1 1/4 inch. Reference data: chain inner width 30.99 mm and roller diameter 27.94 mm. Quality carbon steel, stamped or with welded hub, is the material of SIT pinions, with hardened-tooth or stainless alternatives for special uses. The number of teeth is chosen among the variants, 16. The pitch and inner width of the chain in use should be compared with the data in this sheet before choosing the number of teeth.

Technical Specifications

  • Type: Double pinion for roller chain
  • Chain pitch: 1 3/4 inches (44.45 mm)
  • SIT ISO series: 28B-2 (1 3/4 x 1 1/4 inch)
  • Standard: DIN 8187 - ISO/R 606
  • Chain inner width: 30.99 mm
  • Rows of teeth: 2
  • Number of teeth: 16
  • Material: quality carbon steel
  • Item No.: ITP134D00
  • Brand: SIT

Applications and Uses

  • Transmissions with double chain to increase load capacity
  • Processing machines and plants with high torque
  • Replacement of pinions and sprockets on two-row roller chains
  • Industrial drives with double chain transmission

More details

Brand
SIT
Code
ITP134Z16D

Attachments
