Fiac Ecu 201 oil-free air compressor, suitable for DIY enthusiasts and used mainly for airbrushes and painting.
The compressor is of the coaxial type, which means that the motor's axis of rotation is shared with the shaft of the pump unit, which is directly connected to the motor itself. This improves performance, avoids power losses and reduces overall dimensions.
This compressor is not oil-lubricated and therefore does not release oil particles into the delivered air.
It is easy to carry thanks to its compact size and low weight, and requires no maintenance of any kind.
It features a fully enclosed, impact-resistant wraparound casing that effectively protects the internal rotating parts from dust and damage and protects the user from burns caused by contact with the hot parts of the compressor.
It is equipped with a power cable with plug, pressure reducer, condensate drain, pressure switch with overload protection, filter + reducer, double pressure gauge, sturdy impact-resistant feet and ergonomic handle.
Technical data:
tank capacity: 6 lt
flow rate 205 l/min
maximum pressure: 8 bar - 116 psi
intake air: 205 l/min - 7,3 cfm
rotation speed: 2850 min-1
noise 72 dBA
cylinders/stages: 1/1
dimensions: 430x210x430mm
weight: 17kg
Motor:
power 1.5 HP
kW 1,1
voltage 230 Volt - 50 Hz - 1 ph
