For roller chain with a 1 1/2 inch pitch (38.1 mm): SIT single pinion of the ISO series 24B-1, DIN 8187 and ISO/R 606, with the number of teeth to be chosen among the variants. Item No. ITP112S00.
- Free shipping In Italy on orders from €99.00
- Returns within 14 days How it works
- Secure payments PayPal, cards, Klarna, bank transfer
- WhatsApp support 371 342 6056
Description
Single Pinion for Roller Chain, 1 1/2 Inch Pitch - Item No. ITP112S00
The SIT single pinion with a pitch of 1 1/2 inches has a single row of teeth and works with single roller chains. The SIT catalogue, according to DIN 8187 and ISO/R 606, associates the 1 1/2 inch pitch with series 24B-1, with chain 1 1/2 x 1 inch. Reference data: chain inner width 25.4 mm, roller diameter 25.4 mm, tooth width 24.1 mm. The material is quality carbon steel (stamped or with welded hub); the SIT catalogue also includes pinions with hardened teeth and in stainless steel. The range goes from 9 to 21 teeth and is selected among the variants. The pitch and inner width of the chain in use should be compared with the data in this sheet before choosing the number of teeth.
Technical Specifications
- Type: Single pinion for roller chain
- Chain pitch: 1 1/2 inches (38.1 mm)
- SIT ISO series: 24B-1 (1 1/2 x 1 inch)
- Standard: DIN 8187 - ISO/R 606
- Chain inner width: 25.4 mm
- Tooth width: 24.1 mm
- Rows of teeth: 1
- Number of teeth: from 9 to 21, selectable among the variants
- Material: quality carbon steel
- Item No.: ITP112S00
- Brand: SIT
Applications and Uses
- Traversing and lifting systems
- Chain drives of machine tools and production lines
- Conveyor belts and light handling
- Agricultural machinery and processing plants
More details
- Brand
- SIT
- Code
- ITP112Z13S
