PULLEY FOR TAPER BUSH SECTION "B" 5 GROOVES

Code: PUB1405B
€39.30
VAT excluded: €32.21
Size : 140 5B/2517
In stock 1 piece in stock Ships in 24/48 hours

Description

Taper Bush Pulley, B Section, 5 Grooves - Item No. PBT140SPB5


The pulley with 5 grooves of B section is fixed to the shaft with a SER-SIT taper bush and takes B and SPB belts. The taper bush allows the pulley to be fitted and removed in a short time with a hex key and eliminates the play between shaft and bore, avoiding fretting corrosion. The material is DIN 1691 GG20 - GG25 cast iron; PBT pulleys are statically balanced to ISO standards and suited to a peripheral speed of up to 35 m/s. The pitch diameter, from 140 to 400 mm, and the matching bush (2517, 3020, 3535) are chosen among the variants. For the bush, the SIT catalogue provides a code by size and shaft diameter (for example BC 1610 F20); the bushes are interchangeable with similar types in use worldwide.

Technical Specifications

  • Type: PBT V-pulley for SER-SIT taper bush
  • Material: cast iron DIN 1691 GG20 - GG25
  • Section: B, B and SPB belts
  • Number of grooves: 5
  • Pitch diameter: 140 to 400 mm, to be chosen among the variants
  • Bush: sizes 2517, 3020, 3535, to be chosen among the variants
  • Grooves: according to DIN 2211 - ISO 4183
  • Balancing: static according to ISO
  • Maximum peripheral speed: 35 m/s
  • Item No.: PBT140SPB5
  • Brand: SIT

Applications and Uses

  • Drives that require frequent dismantling
  • Replacement on existing V-belt drives
  • Belt drives of electric motors and industrial machines
  • Compressors, pumps and fans

More details

Brand
SIT
Code
PUB1405B
Manufacturer code
PBT140SPB5
