V-BELT SECTION "B" FROM 100 TO 300

The perforated V-belt is a standard section V‑belt intended for customisable industrial and mechanical applications. Thanks to the regular holes along the back and the dedicated joints, the belt can be made to any length and is sold by the metre, so that it fits any plant or transmission system perfectly.

The section “Z” V-belt is a trapezoidal profile power transmission belt used in light mechanical and industrial applications. Section Z identifies a compact belt, suitable for small-diameter pulleys and for systems where reduced size and good transmission efficiency are required. Various pitch lengths (lengths) are available to suit a wide range of applications.

The SIT VARIO variator belts are special V-belts designed for variable speed transmissions using adjustable-diameter pulleys. These belts are designed to transmit high power in systems with continuous speed adjustment, maintaining high performance and service life even in severe conditions.

The toothed belt XL 037 is a precision mechanical belt for reliable synchronous drives. The designation “XL 037” indicates the belt section, with back width of 0,25 inch (6.35 mm) and tooth pitch of 0,2 inch (5.08 mm). Several variants are available, identified by the belt length expressed in millimetres, to suit any application.

The section “C” V-belts — with designations ranging from C100 to C300 — are classic power transmission belts with a V profile used to transfer power in mechanical and industrial applications. The “C” section indicates a trapezoidal profile with a top width of approximately 22 mm and a height of approximately 14 mm (standard C‑section), compliant with international standards for V‑belts, for reliable transmission between compatible pulleys. The C100…C300 variants refer to increasing pitch lengths, identified by standard codes (linked to the length in inches converted into millimetres).

The Eagle Blue 35 toothed belt is a high-precision mechanical drive belt designed for industrial applications with synchronous drives. The designation “35” identifies the belt width in millimetres (35 mm) and is part of the high-performance SilentSync / Eagle belt family, characterised by low noise, high precision and excellent dynamic behaviour. Several variants with length expressed in millimetres are available, to suit various applications and mechanical systems.

The section “B” V-belts — with codes ranging from B24 to B60 — are trapezoidal-profile drive belts (V‑belts) widely used to transfer power between shafts by means of pulleys with a compatible groove. The section “B” indicates a standard profile with a back width of approximately 17 mm and a height of approximately 11 mm, compliant with ISO/DIN standards for V‑belts. The variants B24…B60 cover various pitch lengths, expressed by international standard codes and available in many lengths in millimetres.

The toothed belt L 075 is a precision mechanical belt, ideal for reliable synchronous drives. The designation “L 075” indicates the belt section, with back width of 0,75 inch (19.05 mm) and tooth pitch of 0,375 inch (9,525 mm). Several variants are available, identified by the belt length expressed in millimetres, to suit any application.

The Eagle Yellow 16 toothed belt is a high-performance synchronous belt, part of the Silent Sync® / Eagle line, designed for quiet, precise and reliable mechanical drives. The number 16 indicates the belt width in millimetres (16 mm). The belt is available in several variants with lengths expressed in millimetres, to suit a wide range of industrial and automation applications.

⚡ Sold by rib: make sure you add the number of ribs required to the quantity (e.g. Ribs = 4 - Quantity = 2 you will receive 2 belts of 4 ribs).
The Poly‑V belt, section J is a multi-rib belt designed to transmit power efficiently on grooved pulleys. It is flexible, compact and suitable for transmissions with several parallel ribs.

The section “B” V-belts — with designations ranging from B61 to B99 — are classic V‑belt power transmission belts designed to transfer power between shafts using pulleys with compatible grooves. Section B indicates a standard trapezoidal profile with a top width of approximately 17 mm and a height of approximately 11 mm, compliant with international V‑belt standards. The B61…B99 variants correspond to different belt pitch lengths, which are identified by standard codes (linked to the length in inches converted into millimetres).

The toothed belt L 100 is a precision mechanical belt, ideal for reliable synchronous drives. The designation “L 100” indicates the belt section, with back width of 1 inch (25.4 mm) and tooth pitch of 0,375 inch (9,525 mm). Several variants are available, identified by the belt length expressed in millimetres, to suit any application.

The section “A” V-belts – with designations ranging from A15 to A60 – are classic V‑belt drive belts used to transfer power between shafts by means of grooved pulleys. The “A” profile indicates a standard trapezoidal section with a back width of approximately 13 mm and a height of approximately 8 mm, compliant with ISO/DIN standards for V‑belts. The variants from A15 to A60 refer to the different pitch lengths of the belt, expressed in standard numbers, and are available in many lengths to suit various mechanical and industrial applications.

The section “A” V-belts – with sizes from A61 to A98 – are classic V‑belt drive belts used to transfer power between shafts by means of pulleys with a compatible groove profile. Section A indicates a trapezoidal profile with standard dimensions of approximately 13 mm top width and 8 mm height, compliant with ISO/DIN standards for V‑belts. The variants A61…A98 refer to the different pitch lengths of the belt, expressed in standard codes, and are available in various lengths in millimetres for many mechanical and industrial applications.

H 100 – Precision toothed belt with back width of 1 inch (25.4 mm) and tooth pitch of 0,5 inch (12.7 mm). Available in various lengths expressed in millimetres, ideal for reliable synchronous drives.

The section “SPZ” V-belt is an industrial V-belt belonging to the SIT SP series, designed for light and medium-light power transmissions. Compared with traditional section Z belts, the SPZ guarantees greater operating stability, better efficiency and longer service life, thanks to a more advanced construction.
