PULLEY FOR TAPER BUSH SECTION "B" 2 GROOVES

Code: PUB1002B
€15.80
VAT excluded: €12.95
Size : 100 2B/1610
In stock 2 pieces in stock Ships in 24/48 hours

Description

Taper Bush Pulley, B Section, 2 Grooves - Item No. PBT250SPB2


Cast iron V-pulley with 2 grooves of B section, designed to be mounted with the SER-SIT taper bush; it accepts B and SPB belts. With the bush, fixing to the shaft is quick and free of play, which prevents fretting corrosion between shaft and bore; a hex key is all that is needed. The DIN 1691 GG20 - GG25 cast iron is turned on numerically controlled machines; static balancing is to ISO and the permitted peripheral speed reaches 35 m/s. The variants provide pitch diameters from 100 to 355 mm, each with its own bush size (1610, 2012, 2517, 3020). The SER-SIT bush is identified by size and shaft diameter, for example BC 1610 F20, and is interchangeable with similar types in use worldwide.

Technical Specifications

  • Type: PBT V-pulley for SER-SIT taper bush
  • Material: cast iron DIN 1691 GG20 - GG25
  • Section: B, B and SPB belts
  • Number of grooves: 2
  • Pitch diameter: 100 to 355 mm, to be chosen among the variants
  • Bush: sizes 1610, 2012, 2517, 3020, to be chosen among the variants
  • Grooves: according to DIN 2211 - ISO 4183
  • Balancing: static according to ISO
  • Maximum peripheral speed: 35 m/s
  • Item No.: PBT250SPB2
  • Brand: SIT

Applications and Uses

  • Replacement on existing V-belt drives
  • Belt drives of electric motors and industrial machines
  • Compressors, pumps and fans

More details

Brand
SIT
Code
PUB1002B
Manufacturer code
PBT100SPB2
