OPTICONTROL REGULATOR FOR GAS MIXTURE

Code: SFM0783788 EAN: 8592346664807
€66.30
VAT excluded: €54.34
In stock 2 pieces in stock Ships in 24/48 hours

Description

Regulator for Argon and Mixtures GCE BaseControl 24 l/min - Item No. 0870418


GCE BaseControl pressure regulator 0870418 for argon and argon-CO2 mixtures, with two gauges and flow adjustment up to 24 litres per minute. The manufacturer specifies it as the replacement for the OptiControl 0783788 regulator, a series discontinued in 2018: anyone who had that model will find the current equivalent here. It screws onto cylinders with the W24.5x1/14 connection and has a G3/8 outlet for the hose to the welding machine. It complies with EN ISO 2503, with a safety valve against overpressure and an on/off valve at the outlet as standard. Forged brass body and aluminium and zinc alloy bonnet; operating temperature from -20 to 60 °C. Suitable for MIG/MAG and TIG welding machines.

Technical Specifications

  • Type: Regulator with flow adjustment
  • Gas: Argon and argon-CO2 mixtures
  • Standard: EN ISO 2503
  • Flow rate: up to 24 l/min
  • Cylinder connection: W24.5x1/14
  • Outlet: G3/8
  • Gauges: 2
  • Replaces: OptiControl 0783788
  • Item No.: 0870418
  • Brand: GCE MUJELLI

Applications and Uses

  • MIG welding with mixtures
  • TIG welding with argon
  • Replacement of OptiControl regulators

More details

Brand
MUJELLI
Code
SFM0783788
EAN13
8592346664807
Manufacturer code
0870418

Recommended accessories and spare parts

SAFETY VALVE MV 93RP OXYGEN 80205

€48.00
AVAILABLE
Availability: 8 In stock

GCE SafeGuard 2 MV93-RP safety valve to fit at the regulator outlet, against flashback and gas return, G3/8 connections, chrome-plated: gas version 80255 and oxygen version 80205 among the variants.
