CAMOZZI REGULATING VALVE RFO

Code: CLRFO38318
€7.70
VAT excluded: €6.31
Size : 383-1/8"
In stock 13 pieces in stock Ships in 24/48 hours

Description

In-Line Bidirectional Flow Regulator Camozzi G1/8 - Item No. RFO 383-1/8


Camozzi RFO 383-1/8 in-line bidirectional flow regulator: it throttles the air passage in both directions and is suited to adjusting an air flow or the speed at which a volume is pressurised and depressurised. It has G1/8 female ports on both sides and is mounted in line, on a panel with the M12x1 threaded ring nut, on the cylinder or on a wall with screws in the through holes of the body. The adjustment is by needle, with a maximum passage of 3 mm. Aluminium body, brass needle, NBR seals. It works from 1 to 10 bar with a nominal pressure of 6 bar, temperature from 0 to 80 °C, with filtered air.

Technical Specifications

  • Type: In-line bidirectional flow regulator
  • Ports: G1/8 female
  • Maximum passage: 3 mm
  • Mounting: In line, on a panel (M12x1), on a wall
  • Operating pressure: 1 to 10 bar (nominal 6)
  • Temperature: 0 to 80 °C
  • Materials: Aluminium body, brass needle, NBR
  • Item No.: RFO 383-1/8
  • Brand: CAMOZZI

Applications and Uses

  • Adjusting blasts and air flows
  • Controlled pressurising and exhausting of volumes
  • Panel mounting on pneumatic cabinets

More details

Brand
CAMOZZI
Code
CLRFO38318
Manufacturer code
RFO 383-1/8
