HI-FLEX

VACUUM GAUGE -1/0 BAR D.63-100 1/4-1/2 RAD/POST

Code: MA10001
€7.60
VAT excluded: €6.23
Size : D.63 0 -1 REAR CONNECTION
Out of stock Usually ships within 10 days

One email when it comes back. No advertising.

Description

Vacuum Gauges 0 / -1 bar - HI-FLEX

Vacuum gauges (gauges for measuring negative pressure or vacuum) brand HI-FLEX, with a scale from 0 to -1 bar. Essential instruments for monitoring the vacuum level in suction systems, vacuum pumps and pneumatic systems. Available in various dial diameter and connection type configurations, with or without glycerine filling.

Technical specifications

  • Type: vacuum gauge (measures negative pressure)
  • Scale: 0 / -1 bar
  • Available configurations: D.63 1/4" radial connection, D.63 1/4" rear connection, D.100 glycerine-filled 1/2" rear connection
  • Glycerine-filled version for environments with vibration
  • Brand: HI-FLEX

Applications and uses

  • Monitoring of vacuum pumps
  • Industrial suction systems
  • Pneumatic and vacuum packaging systems
  • Negative pressure control in hydraulic circuits
Note: Glycerine-filled vacuum gauges are recommended where vibration or pulsation would make readings difficult on dry instruments.
