HI-FLEX

GLYCERIN-FILLED PRESSURE GAUGE D.100 1/2 RAD. 0-1000 bar

Code: MA1000100012
€135.90
VAT excluded: €111.39
Size : 0-1000 1/2"
In stock 3 pieces in stock Ships in 24/48 hours

Description

Glycerine-Filled Pressure Gauges D.100 - 1/2" Radial Connection - HI-FLEX

Glycerine-filled pressure gauges with 100 mm diameter dial, 1/2" BSP radial connection thread, brand HI-FLEX. The glycerine filling dampens vibration and pressure pulsation, protecting the internal mechanism and ensuring a stable, precise reading even in harsh operating conditions. Wide range of scales up to 1000 bar.

Technical specifications

  • Type: glycerine-filled pressure gauge (vibration-resistant)
  • Dial diameter: 100 mm
  • Connection: radial 1/2" BSP
  • Available scales: 0-1, 0-10, 0-25, 0-100, 0-160, 0-250, 0-600, 0-1000 bar
  • Stainless steel case, glycerine filling
  • Brand: HI-FLEX

Applications and uses

  • Hydraulic systems with pressure peaks
  • Hydraulic presses and industrial machinery
  • Compressors and pneumatic systems
  • Environments with strong vibration
Note: The glycerine protects the Bourdon tube mechanism from wear caused by vibration and water hammer, significantly extending the service life of the instrument.

More details

Brand
HI-FLEX
Code
MA1000100012
Manufacturer code
PE567016LF
