PRESSURE GAUGE D.40-63 1/8-1/4 POST. 0-400 bar

Pressure Gauges Rear Connection D.40 / D.50 / D.63 - HI-FLEX

Pressure gauges with rear connection in compact size, available in 40, 50 and 63 mm diameters, brand HI-FLEX. The rear connection allows flush panel mounting with a clean appearance. Available both dry and glycerine-filled, with 1/8" (D.40) and 1/4" (D.50 and D.63) threads. Range of scales from 1 to 400 bar.

Technical specifications

• Type: pressure gauge with rear connection (dry and glycerine-filled)
• Dial diameters: 40, 50 and 63 mm
• Connections: 1/8" BSP (D.40), 1/4" BSP (D.50 and D.63)
• D.40 dry scales: 0-1, 0-6, 0-315 bar
• D.50 and D.63 glycerine-filled scales: 0-16, 0-400 bar
• D.63 dry scales: 0-16 bar
• Brand: HI-FLEX

Applications and uses

• Panel mounting in very limited spaces
• Instrumentation on compact machines and equipment
• Miniaturised control boards
• Pressure regulators with integrated gauge
