CAMOZZI SENSOR BRACKET DIA.32-63

Flange mounting

Mod. E

Accessory for mounting valves on the cylinder

For mounting on valves.

Adjustment by means

of a screwdriver.

Flange mounting

Mod. D

Swivelling one-way and two-way flow regulators

with nominal diameter 1, 5 - 3,5 - 5 mm

Connections: M5, G1/8, G1/4

These one-way and two-way flow regulators have been designed to be mounted directly on valves or cylinders, keeping overall dimensions to a minimum.

The flow rate adjustment characteristic is very wide and gradual, so use is very precise at both the minimum and the maximum flow rate.

For mounting on valve.

Adjustment by means of a manually operated knob. Connections M5, G1/8 and G1/4.

Can be assembled with swivel fittings models 6610; 6620; 1610; 1620; 2023; 1170.

Materials:

Clamp in engineering polymer, O-ring in NBR, nuts and screws in galvanised steel.

Camozzi conveyors with ducted exhausts

Camozzi Hinge Mod C

CAMOZZI SEAL KIT FOR CYLINDERS

CONTACT US FOR INFORMATION ON WHICH TO ORDER!

CAMOZZI SEAL KIT FOR CYLINDERS

CONTACT US FOR INFORMATION ON WHICH TO ORDER!

Since the speed of a cylinder is regulated by restricting the air of the chamber that is exhausting, it is recommended to connect the threaded port of valve 1 to the cylinder inlet and port 2 to the valve user port.

Single sub-base with side outlets ISO 5599/1

Model ZC

CETOP RP 107P

Material:

aluminium

Supplied with:

1x male bracket

Materials:
Clamp in engineering polymer, O-ring in NBR, nuts and screws in galvanised steel.

Rear male hinge mounting Mod. L
