CAMOZZI MOUNTING F

Code: CLF63
€47.40
VAT excluded: €38.85
Size : F 63
In stock 2 pieces in stock Ships in 24/48 hours

Description

Intermediate Hinge Camozzi Mod. F for ISO 15552 Cylinders Bore 63


Camozzi Mod. F intermediate hinge for ISO 15552 pneumatic cylinders with 63 mm bore. It is fixed at the middle of the cylinder barrel and provides two coaxial side pins on which the cylinder can swing: it is the mounting to use when the rod has to follow an arc movement, such as opening doors, levers and tilting. It is in galvanised steel, with 20 mm pins, and is fitted with the grub screws supplied; the pins rest on a pair of dedicated supports, Mod. BF-63-80. The catalogue lists specific versions for Series 61 cylinders, Series 63 profile cylinders and Series 63 round-barrel cylinders: check the series of your cylinder before ordering.

Technical Specifications

  • Type: Swinging intermediate hinge
  • Cylinders: ISO 15552, bore 63 mm
  • Material: Galvanised steel
  • Pins: Diameter 20 mm
  • Compatible supports: Mod. BF-63-80
  • Model: F
  • Brand: CAMOZZI

Applications and Uses

  • Cylinders with swinging arc movement
  • Opening doors, levers and tilting
  • Automatic machines and lifting equipment

More details

Brand
CAMOZZI
Code
CLF63
Manufacturer code
E-40-63
