TOOTHED BELT H 200

The section “C” V-belts — in sizes from C43 to C99 — are standard “V” profile mechanical power transmission belts, designed to transfer power between grooved pulleys in various types of industrial machinery and mechanical applications. The “C” section indicates a trapezoidal profile with standard dimensions of approximately 22 mm top width and 14 mm height according to technical standards for V‑belts. These belts in the C43…C99 range cover a series of increasing pitch lengths, expressed in international standard numbers and useful for easily identifying the correct size.

The section “A” V-belts – with sizes from A61 to A98 – are classic V‑belt drive belts used to transfer power between shafts by means of pulleys with a compatible groove profile. Section A indicates a trapezoidal profile with standard dimensions of approximately 13 mm top width and 8 mm height, compliant with ISO/DIN standards for V‑belts. The variants A61…A98 refer to the different pitch lengths of the belt, expressed in standard codes, and are available in various lengths in millimetres for many mechanical and industrial applications.

H 150 – Precision toothed belt with back width of 1,5 inches (38.1 mm) and tooth pitch of 0,5 inch (12.7 mm). Available in various lengths expressed in millimetres, ideal for synchronous drives.

The toothed belt L 100 is a precision mechanical belt, ideal for reliable synchronous drives. The designation “L 100” indicates the belt section, with back width of 1 inch (25.4 mm) and tooth pitch of 0,375 inch (9,525 mm). Several variants are available, identified by the belt length expressed in millimetres, to suit any application.

The section “B” V-belts — with designations ranging from B100 to B300 — are classic V-profile drive belts designed to transfer power in mechanical and industrial applications. The section “B” indicates a standard trapezoidal profile with a back width of approximately 17 mm and a height of approximately 11 mm, compliant with international standards for V‑belts. The variants B100…B300 refer to increasing pitch lengths, expressed as a code, and allow adaptation to different requirements for transmission between shafts by means of compatible pulleys.

The section “C” V-belts — with designations ranging from C100 to C300 — are classic power transmission belts with a V profile used to transfer power in mechanical and industrial applications. The “C” section indicates a trapezoidal profile with a top width of approximately 22 mm and a height of approximately 14 mm (standard C‑section), compliant with international standards for V‑belts, for reliable transmission between compatible pulleys. The C100…C300 variants refer to increasing pitch lengths, identified by standard codes (linked to the length in inches converted into millimetres).

The Eagle Yellow 16 toothed belt is a high-performance synchronous belt, part of the Silent Sync® / Eagle line, designed for quiet, precise and reliable mechanical drives. The number 16 indicates the belt width in millimetres (16 mm). The belt is available in several variants with lengths expressed in millimetres, to suit a wide range of industrial and automation applications.

H 300 – Precision toothed belt with back width of 3 inches (76.2 mm) and tooth pitch of 0,5 inch (12.7 mm). Available in various lengths expressed in millimetres, ideal for synchronous drives on large machinery.

The section “B” V-belts — with designations ranging from B61 to B99 — are classic V‑belt power transmission belts designed to transfer power between shafts using pulleys with compatible grooves. Section B indicates a standard trapezoidal profile with a top width of approximately 17 mm and a height of approximately 11 mm, compliant with international V‑belt standards. The B61…B99 variants correspond to different belt pitch lengths, which are identified by standard codes (linked to the length in inches converted into millimetres).

H 075 – Precision toothed belt with a back width of 0,75 inches (19.05 mm) and tooth pitch of 0,5 inches (12.7 mm). Available in various lengths expressed in millimetres, suitable for reliable synchronised drives.

The section “SPZ” V-belt is an industrial V-belt belonging to the SIT SP series, designed for light and medium-light power transmissions. Compared with traditional section Z belts, the SPZ guarantees greater operating stability, better efficiency and longer service life, thanks to a more advanced construction.

The SIT section “SPA” V-belt is an industrial V-belt designed to provide greater reliability, stability and service life than traditional section A belts, while maintaining a similar top width. It is used in mechanical applications where consistent performance and greater durability over time are required.

The Eagle Orange 70 toothed belt is a high-performance synchronous drive belt, part of the Silent Sync® / Eagle range designed for industrial applications and mechanical systems requiring precision and reliability. The number 70 indicates the belt width in millimetres (70 mm). The belt is available in several variants with lengths expressed in millimetres, to suit the power transmission and synchronisation requirements of your application.

The section “B” V-belts — with codes ranging from B24 to B60 — are trapezoidal-profile drive belts (V‑belts) widely used to transfer power between shafts by means of pulleys with a compatible groove. The section “B” indicates a standard profile with a back width of approximately 17 mm and a height of approximately 11 mm, compliant with ISO/DIN standards for V‑belts. The variants B24…B60 cover various pitch lengths, expressed by international standard codes and available in many lengths in millimetres.

The toothed belt XL 037 is a precision mechanical belt for reliable synchronous drives. The designation “XL 037” indicates the belt section, with back width of 0,25 inch (6.35 mm) and tooth pitch of 0,2 inch (5.08 mm). Several variants are available, identified by the belt length expressed in millimetres, to suit any application.

The Eagle White 32 toothed belt is a high-performance synchronous belt, part of the Silent Sync® / Eagle range of self-aligning tooth drives designed for industrial applications and precision mechanical systems. The number 32 indicates the belt width in millimetres (32 mm). This belt is available in several variants with lengths expressed in millimetres, to suit the power transmission and synchronisation requirements of your plant.
