CAMOZZI MINI VALVE DEVICE 200-990 M

Code: CL200990
€19.30
VAT excluded: €15.82
In stock 1 piece in stock Ships in 24/48 hours

Description

2-Position Selector for Panel Mini Valves Camozzi Series 2 - Item No. 200-990


Camozzi 200-990 control device for the Series 2 manual panel mini valves: it is a selector with two stable positions, which stays in the chosen position until it is turned again. It is mounted on the panel together with a valve body of the series, 234-000 or 235-000 normally closed and 244-000 or 245-000 normally open, and together they form a 3/2 valve to select operating modes, such as manual or automatic, or to switch a circuit on and off. The complete valves work from 2 to 8 bar with 60 Nl/min. Aluminium valve bodies with brass poppet and NBR seals, M5 ports or ports for 4 mm tube.

Technical Specifications

  • Type: Selector control device
  • Positions: 2, stable
  • Series: 2 panel mini valves
  • Valve bodies: 234-000, 235-000 (NC), 244-000, 245-000 (NO)
  • Complete valve: 3/2, 2 to 8 bar, 60 Nl/min
  • Item No.: 200-990
  • Brand: CAMOZZI

Applications and Uses

  • Selecting operating modes
  • Switching circuits on and off
  • Control panels and pneumatic consoles

More details

Brand
CAMOZZI
Code
CL200990
Manufacturer code
200-990

Attachments

Recommended accessories and spare parts

CAMOZZI NIPPLE ART. 2501

€2.10
AVAILABLE
Availability: 24 In stock

Camozzi Mod. 2501 metric-parallel nipple: double male with equal parallel G threads, in nickel-plated brass, to join two female threaded components. Series 2000. Sizes 1/8 to 1/2 among the variants.

CAMOZZI SILENCER ART. 2921

€4.50
AVAILABLE
Availability: 33 In stock

Camozzi Mod. 2921 silencer with sintered bronze element and copper-plated steel body, for valve exhausts: G1/8 to G3/4 among the variants, up to 10 bar. G1/8: 1730 Nl/min, 81 dB(A).

CAMOZZI FITTING ART.6512

€1.20
AVAILABLE
Availability: 6 In stock

Camozzi 6512 straight male fitting, Series 6000 super-rapid: connection for 4 mm tube and metric male thread M5 or M6 among the variants. Nickel-plated brass, up to 16 bar, weight 4-6 g.

CAMOZZI DEVICE FOR MINI VALVE 210-000

€1.30
AVAILABLE
Availability: 3 In stock

Camozzi element 210-000 for Series 2 manual panel mini valves, listed in the catalogue as a closing base plate (end cover). Completion accessory for 3/2 valves with M5 ports or Ø4 tube.
