CAMOZZI MANUAL VALVE 234-000

Code: CL234000
€21.80
VAT excluded: €17.87
In stock 5 pieces in stock Ships in 24/48 hours

Description

3/2 NC Panel Mini Valve for 4 mm Tube Camozzi Series 2 - Item No. 234-000


Camozzi 234-000 valve body of the Series 2 manual panel mini valves: 3/2 normally closed valve with cartridge-type ports for 4 mm tube, poppet construction. It is fixed on the panel and completed with a control device of the series, 200 codes, such as push button, palm push button, selector, lever, key or pedal: a single valve body gives different controls. The tube is connected directly, without fittings. Aluminium body, brass poppet, NBR seals. It works from 2 to 8 bar with a flow of 60 Nl/min, ambient temperature from 0 to 60 °C. With M5 ports the equivalent body is the 235-000.

Technical Specifications

  • Type: 3/2 NC panel valve body
  • Series: 2 manual mini valves
  • Ports: Cartridge-type for Ø4 mm tube
  • Operating pressure: 2 to 8 bar
  • Flow: 60 Nl/min
  • Control: 200 device to be ordered separately
  • Materials: Aluminium body, brass poppet, NBR
  • Ambient temperature: 0 to 60 °C, fluid 0 to 50 °C
  • Item No.: 234-000
  • Brand: CAMOZZI

Applications and Uses

  • Pneumatic control panels and consoles
  • Manual signals and controls on machines
  • Pneumatic logic circuits

More details

Brand
CAMOZZI
Code
CL234000
Manufacturer code
234-000

Attachments

Recommended accessories and spare parts

CAMOZZI NIPPLE ART. 2501

€2.10
AVAILABLE
Availability: 24 In stock

Camozzi Mod. 2501 metric-parallel nipple: double male with equal parallel G threads, in nickel-plated brass, to join two female threaded components. Series 2000. Sizes 1/8 to 1/2 among the variants.

CAMOZZI SILENCER ART. 2921

€4.50
AVAILABLE
Availability: 33 In stock

Camozzi Mod. 2921 silencer with sintered bronze element and copper-plated steel body, for valve exhausts: G1/8 to G3/4 among the variants, up to 10 bar. G1/8: 1730 Nl/min, 81 dB(A).

CAMOZZI FITTING ART.6512

€1.20
AVAILABLE
Availability: 6 In stock

Camozzi 6512 straight male fitting, Series 6000 super-rapid: connection for 4 mm tube and metric male thread M5 or M6 among the variants. Nickel-plated brass, up to 16 bar, weight 4-6 g.

CAMOZZI DEVICE FOR MINI VALVE 210-000

€1.30
AVAILABLE
Availability: 3 In stock

Camozzi element 210-000 for Series 2 manual panel mini valves, listed in the catalogue as a closing base plate (end cover). Completion accessory for 3/2 valves with M5 ports or Ø4 tube.
