DREMEL VERSATIP SPARE NOZZLE KIT

The 196 is a 3.2 mm high-speed ball cutter (carving/engraving bit) for rotary tools, designed for engraving, shaping and removing material in detail operations on wood, plastic and similar materials. Ideal for precision work, creating grooves and profiles, or making holes and hollows in curved or flat surfaces.

Technical data:

• Type: high-speed ball carving/engraving cutter

• Model: 194 / 26150194JA

• Working diameter: 3.2 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~38 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Quantity in the pack:

• 1 × Dremel cutter 194

Technical applications:

• Engraving, shaping and modelling of wood, plastic, laminates and similar materials

• Creation of grooves, profiles, hollows and holes on flat or curved surfaces

• Decoration and detail work on soft materials

The Dremel 2615MS51JA is a set of multi-purpose blades for the Dremel Moto‑Saw (MS20) jigsaw, designed for straight and curved cuts in wood and plastic. The blades, with 6 teeth per centimetre, offer a good compromise between feed speed and cutting precision, making them suitable for general cutting of light to medium materials.

Technical data:

• Type: serrated blades for Moto‑Saw jigsaw

• Model: 2615MS51JA

• Compatibility: Dremel Moto‑Saw (MS20‑1/5)

• Quantity per pack: 5 pieces

• Overall blade length: 100 mm

• Cutting depth: 18 mm

• Teeth per centimetre: 6 TPI (≈ 6 teeth/cm)

• Blade width: 4.0 mm

• Blade thickness: 0.4 mm

• Blade depth: 2.5 mm

Technical applications:

• Straight and curved cutting in softwood and hardwood, chipboard, laminates and plywood.

• Cutting and finishing of plastic and similar materials for profiling or joints.

Main details:

• Type: pair of replacement brushes for Dremel rotary tool

• Item code: 0615298790 / UEB0615298790

• Application: replacement motor component for Dremel tools

• Dimensions: approx. 5 × 5.5 mm

• Function: replacement of worn brushes to restore motor performance

The Dremel SC402 pin mount is an EZ SpeedClic chuck designed for use with Dremel rotary tools and the EZ SpeedClic system, which allows accessories such as cutting discs and abrasive discs to be fitted and changed quickly without the use of spanners. This accessory makes changing elements faster than with a standard chuck and supports the high rotation speeds suited to multi-tools.

Technical data:

• Type: chuck / pin mount EZ SpeedClic

• Model: SC402

• Shank diameter: 3.2 mm

• Accessory length: 38 mm

• Maximum operating speed: 35,000 rpm

• Accessory change system: EZ SpeedClic – quick tool-free change (Pull–Twist–Release)

• Compatibility: Dremel rotary tools with SpeedClic fitting (for mounting specific discs and compatible accessories)

The Dremel 540 is a set of universal cutting discs for rotary multi-tools, designed mainly for straight cutting of metal and also suitable for wood, plastic, light masonry and composite materials. The discs cut along the edge only and are to be fitted to the tool with the 402 screw mandrel.

Technical data:

• Type: cutting discs for rotary multi-tool

• Model: 540

• Quantity: set of 5 pieces

• Working diameter: 32.0 mm

• Disc thickness: 1.6 mm (typical)

• Shank diameter: 3.2 mm

• Max. cutting depth: 14.0 mm

• Maximum operating speed: ≤ 35 000 rpm

• Shape: thin disc

• Fixing: with 402 screw mandrel

Workable materials: metal (steel, stainless steel, aluminium, copper, brass), sheet metal, bolts/screws, plastic, thin wood, panels, plasterboard and light building materials.

Technical applications:

• Making straight cuts in metal and thin materials

• Cutting bolts, screws and sheet metal without the need for larger tools

• Sectioning plastic materials and light panels with control

The Dremel 723 is a complete 100-piece multi-purpose accessory set designed for use with Dremel rotary multi-tools and other compatible tools with a 3.2 mm chuck. This kit of genuine accessories offers a wide range of components for cutting, sanding, grinding, polishing, cleaning and milling on materials such as wood, metal, plastic and more, making it ideal for DIY projects, workshop use and precision work (also ideal as a starter kit for getting started with the rotary tool).

• Detailed contents – Dremel 723 (100 pieces)

  Mandrels and basic bits

  • 1 × drill bit 150

  • 1 × screw mandrel 401

  • 1 × screw mandrel 402

  • 1 × EZ SpeedClic SC402 mandrel for SpeedClic discs

  Milling / Engraving

  • 1 × high-speed cutter 191

  Grinding stones

  • 1 × aluminium oxide grinding stone Ø 9.5 mm 932

  • 1 × aluminium oxide grinding stone Ø 9.5 mm 952

  • 1 × silicon carbide grinding stone Ø 4.8 mm 84922

  Cutting / grinding wheels and discs

  • 36 × cutting discs Ø 24 mm 409

  • 3 × EZ SpeedClic cutting discs for metal (SC456)

  • 10 × abrasive discs Ø 38 mm 411

  • 8 × abrasive discs Ø 38 mm 413

  Sanding / grinding with bands

  • 1 × sanding band mandrel Ø 6.4 mm + band 430

  • 4 × bands Ø 6.4 mm grit 60 431

  • 4 × bands Ø 6.4 mm grit 120 438

  • 1 × sanding band mandrel Ø 13 mm 407

  • 3 × bands Ø 13 mm grit 60 408

  • 4 × bands Ø 13 mm grit 120 432

  Cleaning / polishing

  • 10 × polishing wheels Ø 13 mm 414

  • 5 × polishing wheels Ø 26 mm 429

  • 1 × bristle brush Ø 19 mm 403

  • 1 × polishing compound 421

  Milling, engraving and detailed work

The Dremel 85422 is a silicon carbide abrasive wheel designed for grinding, deburring and sharpening hard or non-ferrous materials. Thanks to its more durable construction compared with aluminium oxide points, it is suitable for working materials such as glass, ceramic, stone and non-ferrous metals with precision and long working life.

Technical data:

• Type: silicon carbide grinding stone for grinding and deburring on hard surfaces

• Model: 85422

• Working diameter: 19.8 mm

• Shank diameter: 3.2 mm

• Total length: approx. 40 mm

• Shape: thin disc for tapered and flat applications

• Material: abrasive silicon carbide, harder than aluminium oxide stones

• Recommended operating speed: up to 35,000 rpm (varies depending on the material)

• Compatibility: Dremel rotary tools and multi-tools compatible with 3.2 mm accessories

Typical applications:

• Grinding and deburring of hard materials such as ceramic, glass and stone

• Removal of excess glaze or paint from ceramic surfaces

• Sharpening and shaping of non-ferrous surfaces

The Dremel 429 is a felt polishing disc for rotary multi-tools, designed to achieve polished finishes and smooth surfaces on a variety of materials, with or without polishing compounds. It is one of the largest accessories in the Dremel polishing range, suitable when a particularly bright or smooth surface is required.

Technical data:

• Type: felt polishing disc for rotary tools

• Model: 429

• Working diameter: 26.0 mm

• Shank diameter: 3.2 mm

• Material: abrasive polishing felt

• Shape: circular disc

• Recommended maximum operating speed: 20 000 rpm

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm chuck

• Mounting: with threaded mandrel 401 (required for fitting)

Technical applications:

• Polishing and surface finishing of ferrous and non-ferrous metals

• Refining surfaces in plastics and composite materials

• Removal of light machining marks before final polishing

• Preparing surfaces before finishing or painting treatments

The Dremel Art. 425 is a pressed felt polishing disc designed for rotary tools, ideal for achieving glossy, refined finishes on metals and plastic materials. It is intended for use with polishing compound and other polishing discs to obtain a brilliant result on machined surfaces.

Technical data:

• Type: felt polishing disc for rotary tools

• Model: Art. 425

• Working diameter: 22.5 mm (≈ 2.25 cm)

• Shank diameter: 3.2 mm (standard mandrel)

• Material: abrasive polishing felt

• Shape: circular disc

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

• Recommended maximum operating speed: up to approx. 20 000 rpm

• Mounting: by means of a mandrel/clamp suitable for polishing wheels

Technical applications:

• Polishing of metal surfaces such as steel, brass, copper, aluminium and stainless steel for a brilliant effect.

• Surface finishing of hard plastics after grinding and sanding.

• Use with polishing compound to obtain a higher level of shine on machined surfaces.

The Dremel 9911 accessory is a tungsten carbide cutter designed for engraving, carving and material removal on hard surfaces. Thanks to the quality of the material and the shape of the tip, it is suitable for use on a wide range of compact and tough materials.

Technical data:

• Accessory type: engraving / carving cutter

• Model: 9911

• Material: tungsten carbide, highly wear-resistant

• Shank diameter: 3.2 mm

• Working diameter: 3.2 mm

• Accessory length: approx. 39 mm

• Tip shape: conical / oval for effective cutting and engraving

• Maximum recommended speed: up to 30,000 rpm

• Compatibility: rotary tools with a chuck compatible with 3.2 mm accessories

Typical applications: shaping, engraving and material removal on wood, hard metal, stainless steel, cast iron, ceramic, plastic and other compact materials.

The Dremel 482 is a clamping collet for Dremel rotary tools, designed to hold securely bits and accessories with a thin 1.6 mm (≈ 1/16") shank. This type of collet ensures a secure grip of the accessory in the chuck, improving precision and stability during drilling, milling, engraving or other detail operations. It is part of the range of interchangeable collets used to adapt the tool to different accessory diameters.

Technical data:

• Type: clamping collet for rotary tools

• Model: Item 482

• Supported shank diameter: 1.6 mm (≈ 1/16″) (for accessories with a thin shank)

• Material: hard-wearing metal for a secure grip

• Compatibility: Dremel rotary tools with standard chuck (including use with flexible shaft)

• Use: secures the accessory in the chuck for precision work

• Installation: fits into the chuck and is tightened with the multi-tool's clamping nut

Technical applications:

• Holding 1.6 mm bits for drilling, engraving, milling or sanding on materials such as wood, metal or plastic.

• Improves stability and control in detail and precision applications.

The Dremel 196 is a high-speed cylinder cutter (carving/engraving bit) of 6.4 mm for rotary tools, designed for carving, shaping, grooving and material removal in detail work on wood, plastic and similar materials. It is ideal for shaping, creating profiles and precise engraving, offering optimum control in precision work.

Technical data:

• Type: high-speed cylinder cutter for carving/engraving

• Model: 196 / 26150196JA

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~38 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm chuck

Pack quantity:

• 1 × Dremel 196 cutter

Technical applications:

• Shaping and carving of wood, plastic, laminates and similar materials

• Creating grooves, profiles, hollows and holes on flat or curved surfaces

• Engraving and decoration of soft materials

The Dremel 650 is a high-speed steel (HSS) straight cutter designed for rotary tools, intended for milling, straight grooves and linear engraving in soft materials such as wood and plastics. It is ideal for detail work, inlays, profiles and mortises in thin surfaces.

Technical data:

• Type: straight cutter / bit for milling and linear engraving in soft materials

• Model: Art. 650

• Material: high-speed steel (HSS)

• Shank diameter: 3.2 mm

• Working diameter: 3.2 mm

• Effective working length: approx. 1 mm

• Total length: approx. 36 mm

• Shape: straight cut with flat profile

• Maximum recommended operating speed: up to 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm accessory chuck

Technical applications:

• Linear milling and cutting of straight grooves in wood, plywood and laminates

• Inlays and profiles on soft material surfaces

• Engraving channels and mortises for light joints

The item 113 is a cylindrical engraving cutter of 1.6 mm designed for detail work on a wide range of materials. It is specifically made for engraving, shaping and material removal with high-speed rotary tools, offering precision even on curved and complex surfaces.

Technical data:

• Type: engraving / carving cutter

• Model: 113 / 26150113JA

• Working diameter: 1.6 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~45 mm

• Material: high-speed steel

• Recommended maximum operating speed: up to 35 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with 3.2 mm chuck

Quantity in pack:

• 1 × engraving cutter 113 (some packs may include several bits depending on variant)

Technical applications:

• Engraving and detail work on wood, plastic, laminates and similar materials

• Shaping, milling of small surfaces and creation of fine grooves

• Also suitable for work on soft metal, leather, rubber and plexiglass

The Dremel 7134 is a flat-head diamond bit for rotary tools, designed for engraving, carving, precision cutting, finishing and touching up hard and compact materials. The accessory is coated with diamond particles that ensure a high material removal rate and a long service life, ideal for detail work on surfaces that are difficult to machine.

Technical data:

• Type: diamond bit for detailed engraving/cutting/carving

• Model: 7134

• Working diameter: 2.0 mm

• Shank diameter: 3.2 mm

• Total length: approx. 46 mm

• Bit shape: thin flat head for precise engraving

• Material: steel with diamond coating

• Maximum recommended speed: 25 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm accessory chuck

Technical applications:

• Detail engraving on glass, ceramic and stone

• Carving and touching up hardened metal and hard steel

• Cutting and finishing on wood, plastic and composite materials

• Precision work on small and intricate surfaces
