DREMEL ACCESSORY ART.482

The Dremel 430 is a mandrel with abrasive cylinder and abrasive band (60 grit) for rotary tools, designed for sanding, shaping and removing surface finishes on a wide range of materials. The abrasive band can be replaced quickly by loosening the top screw of the mandrel and allows the tool to be adapted to various abrasion operations.

Technical data:

• Type: mandrel with abrasive cylinder and abrasive band

• Model: 430

• Working diameter: 6.4 mm (1/4″)

• Abrasive grit: 60 (coarse)

• Shank diameter: 3.2 mm

• Total length: ~70 mm (approx. 2,75″)

• Abrasive material: aluminium oxide on mandrel band

• Maximum operating speed: up to 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm chuck

Technical applications:

• Sanding, shaping and deburring of wood and wood-based materials

• Removal of rust or old finishes from metal surfaces

• Preparing surfaces in fibreglass, rubber or plastic before further processing

• Rough shaping of profiles or contours before fine finishing

The Dremel 438 is an abrasive cylinder for rotary tools designed for sanding, shaping and finishing surfaces and profiles on various materials. Thanks to its compact shape and suitable abrasive grit, it is effective on wood, metal, plastic and other materials, making this accessory versatile for detail work and surface preparation.

Technical data:

• Type: abrasive cylinder for sanding and shaping

• Model: Item 438

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm (standard for rotary multi-tools)

• Abrasive material: aluminium oxide (medium grit)

• Shape: cylindrical with extended abrasive surface

• Accessory length: approx. 50 mm

• Recommended maximum operating speed: up to approx. 30 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with 3.2 mm mandrel

Technical applications:

• Sanding of surfaces and edges on wood and panels

• Shaping of irregular profiles and curved surfaces

• Removal of rust or light oxidation on metal

• Preparation of plastic or composite surfaces before finishing

The Dremel 569 is a tungsten carbide removal bit designed for Dremel-type rotary tools, specifically for removing mortar or grout from the joints between tiles during renovation or maintenance work. It is intended for spot use or small repairs in combination with the dedicated grout removal attachment (model 568) to keep the bit centred and ensure controlled feed of the tool.

Technical data:

• Type: tungsten carbide grout / mortar removal bit

• Model: 569

• Working diameter: ~1.6 mm (≈ 1⁄16″)

• Shank diameter: 3.2 mm (≈ 1⁄8″), compatible with Dremel rotary tools

• Accessory length: approx. 58 mm

• Material: tungsten carbide

• Recommended operating speed: 15 000 – 20 000 rpm (use with guide and slow feed)

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm shank; can be used with the grout removal attachment 568 to remove grout between tiles

Technical applications:

• Controlled removal of mortar or grout from the joints between tiles before regrouting or resealing

• Preparing tile joints for maintenance or replacement

• Use with a guide/fixing to keep the bit aligned between the tiles

The Dremel 542 is a carbide cutting and shaping disc for rotary tools, designed specifically for cutting, shaping and sanding wood and similar materials such as laminates and fibreboard. The carbide coating ensures longer life and wear resistance when working on hard or soft wood, and also allows grooves and profiles to be made with precision.

Technical data:

• Type: cutting/shaping disc for wood with carbide coating

• Model: Item 542

• Working diameter: 25.4 mm

• Shank diameter: 3.2 mm

• Max. cutting depth: 9.0 mm

• Maximum recommended speed: up to 35 000 rpm

• Workable materials: hard and soft wood, chipboard, plywood, laminates and wood fibreboard

• Compatibility: Dremel rotary tools with 3.2 mm shank

• Pack quantity: 1 disc

Technical applications:

• Cutting and sectioning of wood and wood panels

• Shaping and creating grooves in wooden materials

• Light sanding while cutting thanks to the abrasive carbide coating

Item 105 is a set of 3 engraving cutters, 0.8 mm with a ball head, designed for detail work with high-speed rotary tools. These accessories are ideal for carving, engraving, milling and material removal on a variety of substrates, ensuring precision even on curved surfaces or small details.

Technical data:

• Type: set of engraving cutters / engraving bits

• Model: 105 / 26150105JA

• Working diameter: 0.8 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: approx. 45 mm

• Shape: ball

• Material: high-speed steel

• Maximum recommended speed: up to ~35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Pack quantity:

• 3 × engraving cutters 0.8 mm

Technical applications:

• Engraving and material removal on wood, plastic, laminates and soft metals

• Cutting of grooves, profiles and precision details

• Suitable for detail work, decoration and shaping on flat or curved surfaces

The Dremel 670 is a mini circular saw to attach to a Dremel rotary multi-tool, designed to make clean, straight cuts in wood and wood-like materials. It turns your multi-tool into a small portable saw with an integrated directional guide and a transparent guard for better visibility while cutting.

Technical data:

• Type: mini circular saw attachment for multi-tool

• Compatibility: suitable for Dremel models and other rotary tools compatible with the quick connect system

• Standard blade included: mini circular blade Ø 31.8 mm

• Maximum cutting depth: 6.35 mm

• Structure: angled base for perpendicular cuts with directional guide

• Transparent guard for visibility of the cutting area

• Attachment length: approx. 50 mm

• Overall width: approx. 90 mm

• Overall depth: approx. 45 mm

• Use: thin, precise cuts in wood, laminates and similar materials

The Dremel 422 is a felt polishing bit for rotary tools, designed for the polishing and surface finishing of metals, plastics and other materials. Its compact profile and felt construction also make it suitable for cleaning details, holes or hard-to-reach surfaces, and it can be used with or without polishing compound to obtain a smooth, shiny surface.

Technical data:

• Type: felt polishing bit/cylinder for rotary tools

• Model: Art. 422

• Working diameter: 10 mm

• Shank diameter: 3.2 mm (standard mandrel)

• Material: abrasive polishing felt

• Shape: polishing cone/cylinder

• Recommended maximum operating speed: up to 20 000 rpm

• Compatibility: Dremel type rotary tools with a 3.2 mm chuck (use with a suitable pin/clamp)

Technical applications:

• Polishing of ferrous and non-ferrous metals (steel, brass, aluminium, silver, etc.)

• Finishing and polishing of plastics and perspex after abrasive operations

• Cleaning of details, corners and holes thanks to the conical shape

• Use with or without polishing compound/paste to obtain different finishes

The Dremel 540 is a set of universal cutting discs for rotary multi-tools, designed mainly for straight cutting of metal and also suitable for wood, plastic, light masonry and composite materials. The discs cut along the edge only and are to be fitted to the tool with the 402 screw mandrel.

Technical data:

• Type: cutting discs for rotary multi-tool

• Model: 540

• Quantity: set of 5 pieces

• Working diameter: 32.0 mm

• Disc thickness: 1.6 mm (typical)

• Shank diameter: 3.2 mm

• Max. cutting depth: 14.0 mm

• Maximum operating speed: ≤ 35 000 rpm

• Shape: thin disc

• Fixing: with 402 screw mandrel

Workable materials: metal (steel, stainless steel, aluminium, copper, brass), sheet metal, bolts/screws, plastic, thin wood, panels, plasterboard and light building materials.

Technical applications:

• Making straight cuts in metal and thin materials

• Cutting bolts, screws and sheet metal without the need for larger tools

• Sectioning plastic materials and light panels with control

The Dremel 7103 is a 2 mm diamond ball bit for rotary tools, designed for engraving, carving and precision detail work on particularly hard or tough materials. The coating of diamond particles gives greater surface hardness and better performance than traditional abrasive accessories, making it suitable for many finishing applications.

Technical data:

• Type: diamond ball bit for engraving/carving

• Model: 7103

• Working diameter: 2.0 mm

• Shank diameter: 3.2 mm

• Accessory length: 45.0 mm

• Material: steel with diamond coating

• Shape: spherical → allows concave engraving, grooves and detailed relief work

• Recommended maximum operating speed: up to approx. 25 000 rpm

• Quantity: set of 2 diamond bits

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm accessory chuck

Typical applications:

• Precision engraving and carving on glass, ceramic and porcelain

• Shaping and touching up on hardened metal and wood

• Detail work on hard and brittle materials

• Finishing and decorating work for hobbyists and professional projects

The Dremel SC 407 is an EZ SpeedClic sanding set consisting of a mandrel with a quick-change system and two 13 mm sanding bands of different grits, designed for sanding, shaping and material removal on wood, plastic, soft metals and other materials. The EZ SpeedClic™ system allows accessories to be changed without the use of spanners, making use quicker and more intuitive.

Technical data:

• Type: EZ SpeedClic mandrel + sanding bands for sanding

• Model: SC 407

• Shank diameter: 3.2 mm

• Band working diameter: 13.0 mm

• Abrasive material: aluminium oxide

• Grits included: 60 (more aggressive) and 120 (finer)

• Compatibility: rotary tools with 3.2 mm chuck and EZ SpeedClic™ system

• Recommended operating speed: up to 35 000 rpm

• Mounting system: EZ SpeedClic™ — tool-free accessory change

Exact package contents:

• 1 × EZ SpeedClic sanding mandrel

• 1 × 13 mm sanding band, grit 60 (very aggressive)

• 1 × 13 mm sanding band, grit 120 (finer)

Technical applications:

• Sanding and material removal on softwood and hardwood

• Roughing and finishing on plastics and composite materials

• Cleaning and removal of light oxidation from soft metals

• Contouring and surface preparation before finishing

The Dremel 537 accessory is a brass brush for rotary tools designed for cleaning and surface finishing of relatively soft and delicate metals, ideal for removing oxidation and residues and for creating a satin or matt finish without scratching the surface. The brass bristles are non‑sparking and softer than steel, reducing the risk of damaging sensitive materials.

Technical data:

• Type: brass brush for cleaning/polishing

• Model: 537

• Shank diameter: 3.2 mm

• Working diameter: 3.2 mm

• Bristle material: brass (wire brass)

• Shape: rotary brush

• Accessory length: approx. 48 mm

• Maximum operating speed: 15 000 rpm

• Compatibility: rotary tools with 3.2 mm shank (Dremel and compatible)

Technical applications:

• Cleaning of soft metal surfaces such as gold, bronze, copper and brass without generating sparks

• Surface finishing to achieve a satin or matt effect

• Removal of oxidation and residues from joints or hard-to-reach points

• Surface preparation before further machining or fine polishing

The item 193 is a 2.4 mm high-speed ball cutter (carving/engraving bit) for rotary tools, designed for engraving, shaping and removing material in detail work on wood, plastic and similar materials. Ideal for precision operations, creating grooves and profiles, or making hollows and small holes on curved or flat surfaces.

Technical data:

• Type: high-speed ball carving/engraving cutter

• Model: 193 / 26150193JA

• Working diameter: 2.4 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~38 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Quantity in the pack:

• 1 × item 193

Technical applications:

• Engraving, shaping and modelling of wood, plastic, laminates and similar materials

• Creation of grooves, profiles, hollows and small holes on flat or curved surfaces

• Decoration and detail work on soft materials

The Dremel 8153 is a cylindrical aluminium oxide grinding stone designed for rotary tools with a 3.2 mm shank fitting, ideal for grinding, deburring and sharpening on a wide range of metallic materials and alloys. The shape and dimensions of the abrasive body also allow it to work effectively on tapered surfaces and irregular profiles.

Technical data:

• Type: grinding stone for general grinding and deburring on metal and ferrous materials.

• Model: 8153.

• Quantity: 1 piece.

• Abrasive material: aluminium oxide.

• Shape: cylindrical.

• Working diameter: 4.8 mm.

• Shank diameter: 3.2 mm.

• Accessory length: approx. 38 mm.

• Recommended maximum operating speed: up to 25 000 rpm.

• Compatibility: for use with Dremel rotary multi-tools and other compatible tools with a 3.2 mm chuck.

Technical applications:

• Sharpening of blades, drill bits and cutting tools.

• Deburring and smoothing of welded joints and castings.

• Removal of rivets, rust and excess material on metal.

• Preparation of metal surfaces before finishing.

The Dremel 429 is a felt polishing disc for rotary multi-tools, designed to achieve polished finishes and smooth surfaces on a variety of materials, with or without polishing compounds. It is one of the largest accessories in the Dremel polishing range, suitable when a particularly bright or smooth surface is required.

Technical data:

• Type: felt polishing disc for rotary tools

• Model: 429

• Working diameter: 26.0 mm

• Shank diameter: 3.2 mm

• Material: abrasive polishing felt

• Shape: circular disc

• Recommended maximum operating speed: 20 000 rpm

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm chuck

• Mounting: with threaded mandrel 401 (required for fitting)

Technical applications:

• Polishing and surface finishing of ferrous and non-ferrous metals

• Refining surfaces in plastics and composite materials

• Removal of light machining marks before final polishing

• Preparing surfaces before finishing or painting treatments

The Dremel 199 is a high-speed cutter (carving/engraving bit) of 9.5 mm for rotary tools, designed for carving, engraving, grooving and material removal in detail work on various materials. It is a versatile accessory for shaping, creating profiles and grooves or making tapered holes, ideal for precision work.

Technical data:

• Type: high-speed cutter for carving/engraving

• Model: 199 / 26150199JA

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~39 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm chuck

Pack quantity:

• 1 × Dremel 199 cutter

Technical applications:

• Shaping and carving of wood, plastic, laminates and similar materials

• Creating grooves, profiles, hollows and tapered holes on flat or curved surfaces

• Engraving and decoration on soft materials
