REGULATOR SERIES N 1204R00 1/4

KIT FOR MC FILTER 1/4"

Series name N

Construction type Oil mist

Bowl material Transparent PA12

Size Standard bowl (37 cm³)

Function LUBRICATOR

Connections G1/4

MX Series filter-regulators consist of a filter and an integrated pressure reducer.

They are therefore compact and suitable for pre-filtering functions.

Available with or without relieving, they are fitted with a diaphragm valve for direct pressure regulation and an integrated manual or automatic condensate drain.

They are also fitted with a recessed pressure gauge.

The MX Series offers multi-sector solutions that save installation time, space and costs.

Anodised pneumatic manifold 320/3A with 5 ports of 1/2” for compressed air branching in industrial systems.

Filter element 25 µm

Series name N

Bowl material Transparent PA12

Size Standard bowl (28 cm³)

Condensate drain Semi-automatic manual

Function FILTER

Connections G1/4

Minimum working pressure [Bar] 0.5 ÷ 10 bar

Filter element 25 µm, with relieving

Series name MX

Size G3/8 - G1/2 - G3/4

Pressure gauge With recessed 0-12 pressure gauge, working pressure 0.5 ÷ 10 bar

Condensate drain Automatic

Connections G3/8

Filter-regulator FILTER-REGULATOR

Flow direction Left to right

ANI 31/A4 (Air 11) pressure regulator for compressed air, with 40 mm round pressure gauge, 0-16 bar scale, satin-finish aluminium body and 1/4 BSP connections.

Minimum working pressure [Bar] 0.5 ÷ 10 bar

Filter element 25μm

Series name N

Bowl material Transparent PA12

Size Standard bowl (28 cm³)

Condensate drain Manual semi-automatic with relieving

Function FILTER-REGULATORS

Connections G1/4

Minimum working pressure [Bar] 0.5 ÷ 10 bar

Series name M

Construction type Relieving

Adjustment Without bypass valve

Size 0

Pressure gauge Without pressure gauge

Function REGULATOR

Connections G1/4

Condensate drain for pneumatic systems up to 16 bar, 230 V AC, complete with cable and connector for industrial automation.

220 V 4-way air pressure switch with switch for automatic pressure control in pneumatic systems.

Generic brass fittings for pneumatic systems, compatible with standard compressed air hoses and fittings.

Minimum working pressure [Bar] 0.5 ÷ 10 bar

Regulator type Pressure regulator

Series name MX

Construction type Relieving

Size G3/4 - G1

Pressure gauge With recessed 0-12 pressure gauge, working pressure 0.5 ÷ 10 bar

Connections G1

Flow direction Left to right

Filter element 25μm

Regulator type Without bypass valve

Working pressure 0.5 ÷ 10

Series name MC

Size G1/4

Pressure gauge Without pressure gauge (standard)

Condensate drain Manual-semi-automatic, with relieving

Function FILTER-REGULATOR

Connections G1/4

Giant air tap model 19B with female-female connections for flow control in pneumatic systems.

Camozzi MC series filter with automatic condensate drain
