DREMEL MULTI-PURPOSE WOOD BLADES MOTO-SAW_5 MULTI-PURPOSE WOOD BLADES

The Dremel 540 is a set of universal cutting discs for rotary multi-tools, designed mainly for straight cutting of metal and also suitable for wood, plastic, light masonry and composite materials. The discs cut along the edge only and are to be fitted to the tool with the 402 screw mandrel.

Technical data:

• Type: cutting discs for rotary multi-tool

• Model: 540

• Quantity: set of 5 pieces

• Working diameter: 32.0 mm

• Disc thickness: 1.6 mm (typical)

• Shank diameter: 3.2 mm

• Max. cutting depth: 14.0 mm

• Maximum operating speed: ≤ 35 000 rpm

• Shape: thin disc

• Fixing: with 402 screw mandrel

Workable materials: metal (steel, stainless steel, aluminium, copper, brass), sheet metal, bolts/screws, plastic, thin wood, panels, plasterboard and light building materials.

Technical applications:

• Making straight cuts in metal and thin materials

• Cutting bolts, screws and sheet metal without the need for larger tools

• Sectioning plastic materials and light panels with control

The TR 615 cutter is an accessory for Dremel TRIO tools designed specifically for rounding and shaping corners and edges on soft materials such as wood, plastic, rubber and Plexiglas. The tool produces rounded profiles and softer finishes on surfaces of small craft projects and detail work.

Technical data:

• Type: edge-rounding cutter

• Model: TR 615

• Working diameter: 9.5 mm

• Shank diameter: 4.8 mm

• Recommended materials: hardwood, softwood, rubber, plastic, Plexiglas, carbon

• Compatibility: dedicated accessory for Dremel TRIO (not suitable for traditional multi-tools without a TRIO adapter)

• Shape: rounded profile for chamfering and finishing corners

The Dremel 84922JA is a set of silicon carbide abrasive points for rotary tools with a standard 3.2 mm shank. These small conical points are designed for grinding, deburring and engraving on hard or non-ferrous materials where traditional aluminium oxide points are less effective.

Technical data:

• Type: silicon carbide abrasive points for grinding and deburring

• Model: 84922JA

• Pack quantity: set of 3 pieces

• Working diameter: 4.8 mm

• Shank diameter: 3.2 mm

• Shape: small cone for access to surfaces and details

• Abrasive material: silicon carbide, more durable than aluminium oxide points

• Accessory length: approx. 40 mm

• Recommended maximum operating speed: up to 25 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a chuck for 3.2 mm accessories

Technical applications:

• Grinding and deburring of hard and brittle materials such as glass, ceramic, porcelain, stone and non-ferrous metals

• Engraving and material removal on uneven surfaces

• Preparation of complex surfaces before finishing

The Dremel 569 is a tungsten carbide removal bit designed for Dremel-type rotary tools, specifically for removing mortar or grout from the joints between tiles during renovation or maintenance work. It is intended for spot use or small repairs in combination with the dedicated grout removal attachment (model 568) to keep the bit centred and ensure controlled feed of the tool.

Technical data:

• Type: tungsten carbide grout / mortar removal bit

• Model: 569

• Working diameter: ~1.6 mm (≈ 1⁄16″)

• Shank diameter: 3.2 mm (≈ 1⁄8″), compatible with Dremel rotary tools

• Accessory length: approx. 58 mm

• Material: tungsten carbide

• Recommended operating speed: 15 000 – 20 000 rpm (use with guide and slow feed)

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm shank; can be used with the grout removal attachment 568 to remove grout between tiles

Technical applications:

• Controlled removal of mortar or grout from the joints between tiles before regrouting or resealing

• Preparing tile joints for maintenance or replacement

• Use with a guide/fixing to keep the bit aligned between the tiles

The Dremel 26159929JA, also identified as accessory 9929, is a diamond engraving bit designed to work with the Dremel 290 engraver and compatible rotary tools. Thanks to its diamond-coated head, it offers longer life and wear resistance compared with standard bits, allowing harder materials such as glass and stainless steel to be engraved with precision and control.

Technical data:

• Type: diamond engraving bit

• Model: 9929 / 26159929JA

• Bit material: diamond / diamond coating

• Bit diameter: ~3 mm

• Overall length: ~20 mm

• Tool compatibility: Dremel 290‑1 / 290‑3 Hobby engraver and multi-tools with a chuck suitable for engraving

• Quantity per pack: 1 diamond bit

Technical use:

• Engraving of glass, ceramic, marble, stainless steel and hard materials

• Creating thin lines, grooves and precise details on difficult surfaces

• Suitable for craft projects, model making and precision work

Item 111 is a small-diameter (0.8 mm) engraving cutter with an elongated cylindrical head, designed for extremely precise detail work with high-speed rotary tools. It allows engraving, shaping and material removal even on curved surfaces, making it suitable for carving and micro-machining operations on various materials such as wood, plastic, fibreglass, rubber and soft metals.

Technical data:

• Type: engraving cutter / cylindrical carving bit

• Model: 111 / 26150111JA

• Working diameter: 0.8 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: approx. 45 mm

• Material: high-speed steel

• Maximum recommended operating speed: up to approx. 35 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm chuck

Pack quantity:

• 3 × engraving cutter 111

Technical applications:

• Engraving, shaping and milling of details on wood, plastic, laminated materials and rubber

• Precision work, grooves, profiles and localised material removal

• Ideal on curved or irregular surfaces thanks to the elongated shape of the cutter

The Dremel Art. 636 is a drill bit set specifically for wood, designed for precision drilling in wood and similar materials with compatible rotary tools. Each bit features a centring point for a precise, straight start to the hole and a titanium coating for longer life and consistent performance.

Technical data:

• Type: wood drill bit set for rotary tools

• Model: 636

• Number of bits included: 4 pieces

• Working diameters: 3 mm, 4 mm, 5 mm, 6 mm

• Shank diameter: 3.2 mm (1/8″)

• Coating: titanium for long service life

• Centring point: yes, for accurate holes and a straight entry

• Recommended use: drilling in softwood, hardwood, laminate, plywood, chipboard and fibreboard

• Maximum recommended operating speed: up to 35 000 rpm

• Typical applications: precision drilling in wood, making holes from Ø 3 mm to Ø 6 mm, preparing joints, screw pilot holes and craft details

The Dremel Art. 953 is a set of 3 aluminium oxide grinding stones for rotary tools, designed for grinding, deburring and sharpening on metal and ferrous materials. The conical components allow work on conical and curved surfaces and joints, delivering effective finishes and controlled material removal.

Technical data:

• Model: 953

• Quantity: 3 grinding stones per pack

• Abrasive material: aluminium oxide

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 40 mm

• Shape: conical / versatile for curved surfaces

• Applications: smoothing, deburring and sharpening on metal, castings, welded joints, rivets and rust removal

• Maximum operating speed: up to 25,000 rpm

• Compatibility: rotary tools that accept accessories with a 3.2 mm shank

Typical use:

• Removal of burrs from cuts in metal

• Smoothing of welded joints and castings

• Sharpening of tools and metal edges

• Removal of rivets and rust on ferrous surfaces

The Dremel SC 407 is an EZ SpeedClic sanding set consisting of a mandrel with a quick-change system and two 13 mm sanding bands of different grits, designed for sanding, shaping and material removal on wood, plastic, soft metals and other materials. The EZ SpeedClic™ system allows accessories to be changed without the use of spanners, making use quicker and more intuitive.

Technical data:

• Type: EZ SpeedClic mandrel + sanding bands for sanding

• Model: SC 407

• Shank diameter: 3.2 mm

• Band working diameter: 13.0 mm

• Abrasive material: aluminium oxide

• Grits included: 60 (more aggressive) and 120 (finer)

• Compatibility: rotary tools with 3.2 mm chuck and EZ SpeedClic™ system

• Recommended operating speed: up to 35 000 rpm

• Mounting system: EZ SpeedClic™ — tool-free accessory change

Exact package contents:

• 1 × EZ SpeedClic sanding mandrel

• 1 × 13 mm sanding band, grit 60 (very aggressive)

• 1 × 13 mm sanding band, grit 120 (finer)

Technical applications:

• Sanding and material removal on softwood and hardwood

• Roughing and finishing on plastics and composite materials

• Cleaning and removal of light oxidation from soft metals

• Contouring and surface preparation before finishing

The item 192 is a 4.8 mm high-speed tapered cutter (carving/engraving bit) for rotary tools, designed for shaping, engraving and removing material in precision work on wood, plastic and similar materials. Ideal for creating grooves, profiles, hollows and small tapered holes on flat or curved surfaces.

Technical data:

• Type: high-speed tapered carving/engraving cutter

• Model: 192 / 26150192JA

• Working diameter: 4.8 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~38 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Quantity in the pack:

• 2 × item 192

Technical applications:

• Shaping and engraving of wood, plastic, laminates and similar materials

• Creation of grooves, profiles, hollows and small tapered holes

• Detail work and decoration on soft materials

The Dremel Art. 425 is a pressed felt polishing disc designed for rotary tools, ideal for achieving glossy, refined finishes on metals and plastic materials. It is intended for use with polishing compound and other polishing discs to obtain a brilliant result on machined surfaces.

Technical data:

• Type: felt polishing disc for rotary tools

• Model: Art. 425

• Working diameter: 22.5 mm (≈ 2.25 cm)

• Shank diameter: 3.2 mm (standard mandrel)

• Material: abrasive polishing felt

• Shape: circular disc

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

• Recommended maximum operating speed: up to approx. 20 000 rpm

• Mounting: by means of a mandrel/clamp suitable for polishing wheels

Technical applications:

• Polishing of metal surfaces such as steel, brass, copper, aluminium and stainless steel for a brilliant effect.

• Surface finishing of hard plastics after grinding and sanding.

• Use with polishing compound to obtain a higher level of shine on machined surfaces.

The Dremel 439 is a replacement abrasive cylinder for rotary tools, used in combination with the mandrel and abrasive band to sand, shape and finish various types of surface. The medium grit makes it suitable for material removal and shaping on wood, metal, fibreglass, rubber and other similar materials.

Technical data:

• Type: abrasive cylinder for sanding/shaping

• Model: Item 439

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm (standard for rotary tools)

• Abrasive grit: approx. 60 (medium)

• Material: abrasive on rotating cylinder

• Shape: abrasive cylinder

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm mandrel

Technical applications:

• Sanding and material removal on wood, plywood and fibreglass

• Removal of rust or light oxidation from metal surfaces

• Shaping of profiles and surfaces on materials such as rubber and plastic

• Surface preparation before finishing or painting

The Dremel 530 accessory is a circular brush with stainless steel bristles for rotary multi-tools, designed for cleaning, deburring and surface polishing on corrosion-sensitive or delicate materials. The stainless steel bristles reduce the risk of oxidation after treatment and are also effective on flat surfaces and in hard-to-reach places.

Technical data:

• Type: circular stainless steel brush for rotary tools

• Model: 530

• Working diameter: 19.0 mm

• Shank diameter: 3.2 mm (1/8″)

• Overall length: approx. 44 mm

• Bristle material: stainless steel

• Shape: circular radial brush

• Recommended maximum operating speed: up to 15 000 rpm

• Compatibility: rotary tools with 3.2 mm chuck

Technical applications:

• Cleaning and removal of oxidation from stainless steel, aluminium and non-ferrous metals

• Deburring of edges and joints on metal surfaces

• Surface finishing of silver, brass and copper parts

• Surface preparation before painting or further treatments

The Dremel 535 is a stiff-wire steel brush for rotary tools, designed for removal of rust, oxidation, old paint and surface deposits from metals and hard surfaces. The circular construction with steel bristles provides aggressive and effective cleaning while maintaining control and precision in detail work.

Technical data:

• Type: circular steel brush for cleaning and deburring

• Model: 535

• Working diameter: approx. 9.5 mm

• Shank diameter: 3.2 mm (standard for rotary multi-tools)

• Bristle material: tempered steel

• Shape: circular “brush-type” brush

• Overall accessory length: approx. 48 mm

• Recommended maximum operating speed: up to 15 000 – 20 000 rpm

• Compatibility: rotary tools with 3.2 mm chuck

Typical applications:

• Removal of rust and oxidation from metal surfaces

• Cleaning of ferrous parts before painting or welding

• Deburring and finishing of metal joints

• Surface preparation of hard metal materials

• Rough polishing of surfaces after abrasive machining

The Dremel 432 is a set of abrasive bands (abrasive cylinders) for rotary tools, designed for sanding, shaping and surface cleaning on different materials. The 120 grit aluminium oxide coating offers a good balance between material removal and finish, making these bands ideal for surface preparation and finishing.

Technical data:

• Type: abrasive bands/cylinders for abrasion and sanding

• Model: 432

• Working diameter: approx. 13 mm (½″)

• Abrasive grit: 120 (medium/fine)

• Shank diameter: 3.2 mm (standard for rotary tools)

• Maximum operating speed: up to ~35 000 rpm

• Quantity: normally sold in packs of several pieces (e.g. 6 bands)

• Compatibility: Dremel-type rotary tools with 3.2 mm mandrel

Technical applications:

• Sanding and shaping of wood surfaces and plywood

• Rust removal and cleaning of metal surfaces

• Shaping and finishing of rubber, fibreglass and plastic

• Surface preparation before painting or other finishing

The Dremel 4485 is a collet kit with collet nut for Dremel series rotary tools, designed to hold a wide range of bits and accessories firmly with different shank diameters. The set lets you adapt the tool to the correct accessory size, ensuring a stable grip and reducing vibration or slipping during use. This accessory is a simple and versatile solution for anyone who frequently uses bits of different diameters on rotary multi-tools.

Technical data:

• Type: collet set with collet nut for rotary multi-tool

• Model: 4485

• Contents:

  • 1 × collet nut

  • 4 × collets of diameters: 0.8 mm, 1.6 mm, 2.4 mm, 3.2 mm

• Supported accessory diameter range: 0.8 mm – 3.2 mm

• Tool compatibility: Dremel rotary multi-tools (cordless and corded) with a chuck for traditional collets

• Recommended maximum speed: up to 35 000 rpm

• Material: sturdy metal for a stable grip and long operating life

• Installation: screws onto the front thread of the tool, and the collets are fitted to clamp the accessories

Technical applications:

• Precise clamping of bits, cutters, grinding wheels, brushes or other accessories in the supported diameters.

• Improves the stability and control of the accessory when working on wood, metal, plastic and other materials.

• Ideal for anyone who uses several tool diameters with the same rotary tool.
