DREMEL MILLING CUTTER 569

The Dremel 422 is a felt polishing bit for rotary tools, designed for the polishing and surface finishing of metals, plastics and other materials. Its compact profile and felt construction also make it suitable for cleaning details, holes or hard-to-reach surfaces, and it can be used with or without polishing compound to obtain a smooth, shiny surface.

Technical data:

• Type: felt polishing bit/cylinder for rotary tools

• Model: Art. 422

• Working diameter: 10 mm

• Shank diameter: 3.2 mm (standard mandrel)

• Material: abrasive polishing felt

• Shape: polishing cone/cylinder

• Recommended maximum operating speed: up to 20 000 rpm

• Compatibility: Dremel type rotary tools with a 3.2 mm chuck (use with a suitable pin/clamp)

Technical applications:

• Polishing of ferrous and non-ferrous metals (steel, brass, aluminium, silver, etc.)

• Finishing and polishing of plastics and perspex after abrasive operations

• Cleaning of details, corners and holes thanks to the conical shape

• Use with or without polishing compound/paste to obtain different finishes

The Dremel 520 is an impregnated polishing pad for rotary tools, featuring abrasive and lubricant already built into the structure of the accessory. It is designed for light material removal and high-gloss polishing on metal and other materials, without the need to apply external polishing paste.

Technical data:

• Type: impregnated polishing pad/wheel

• Model: 520

• Working diameter: approx. 13.2 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 54 mm

• Material: felt backing impregnated with silicon carbide abrasive and lubricant

• Recommended maximum speed: up to 20 000 rpm

• Compatibility: rotary tools with 3.2 mm chuck (Dremel series and compatible)

Technical applications:

• Polishing and bright finishing of metal surfaces (steel, aluminium, brass, silver, etc.)

• Light removal of imperfections before further finishing

• Polishing of hard plastics and non-metallic materials for glossy finishes without external pastes

The Dremel 2615MS51JA is a set of multi-purpose blades for the Dremel Moto‑Saw (MS20) jigsaw, designed for straight and curved cuts in wood and plastic. The blades, with 6 teeth per centimetre, offer a good compromise between feed speed and cutting precision, making them suitable for general cutting of light to medium materials.

Technical data:

• Type: serrated blades for Moto‑Saw jigsaw

• Model: 2615MS51JA

• Compatibility: Dremel Moto‑Saw (MS20‑1/5)

• Quantity per pack: 5 pieces

• Overall blade length: 100 mm

• Cutting depth: 18 mm

• Teeth per centimetre: 6 TPI (≈ 6 teeth/cm)

• Blade width: 4.0 mm

• Blade thickness: 0.4 mm

• Blade depth: 2.5 mm

Technical applications:

• Straight and curved cutting in softwood and hardwood, chipboard, laminates and plywood.

• Cutting and finishing of plastic and similar materials for profiling or joints.

Dremel 108 engraving cutter is an engraving cutter/engraving bit with a cylindrical shape, 0.8 mm, designed for detail work with high-speed rotary tools. This tool allows you to carve, engrave, mill and create grooves with precision on materials such as wood, plastic, leather, rubber and soft metals, and is also suitable for curved or complex surfaces.

Technical data:

• Type: engraving cutter / engraving bit

• Model: 108 / 26150108JA

• Working diameter: 0.8 mm (approx. 1/32 in)

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: approx. 45 mm

• Material: high-speed steel / hardened steel for general use

• Maximum recommended operating speed: up to approx. 35 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm chuck

Pack quantity:

• 3 × engraving cutters 0.8 mm

Technical applications:

• Engraving, shaping and material removal on wood, plastic, laminates, fibreglass and soft metals

• Creation of grooves, profiles, tapered holes and details on flat or curved surfaces

• Ideal for precision work, decoration and artistic carving on soft materials

The Dremel SC 407 is an EZ SpeedClic sanding set consisting of a mandrel with a quick-change system and two 13 mm sanding bands of different grits, designed for sanding, shaping and material removal on wood, plastic, soft metals and other materials. The EZ SpeedClic™ system allows accessories to be changed without the use of spanners, making use quicker and more intuitive.

Technical data:

• Type: EZ SpeedClic mandrel + sanding bands for sanding

• Model: SC 407

• Shank diameter: 3.2 mm

• Band working diameter: 13.0 mm

• Abrasive material: aluminium oxide

• Grits included: 60 (more aggressive) and 120 (finer)

• Compatibility: rotary tools with 3.2 mm chuck and EZ SpeedClic™ system

• Recommended operating speed: up to 35 000 rpm

• Mounting system: EZ SpeedClic™ — tool-free accessory change

Exact package contents:

• 1 × EZ SpeedClic sanding mandrel

• 1 × 13 mm sanding band, grit 60 (very aggressive)

• 1 × 13 mm sanding band, grit 120 (finer)

Technical applications:

• Sanding and material removal on softwood and hardwood

• Roughing and finishing on plastics and composite materials

• Cleaning and removal of light oxidation from soft metals

• Contouring and surface preparation before finishing

Set of 5 thin cutting discs for rotary tools with EZ SpeedClic fitting, designed for precise cuts in metal and metallic materials such as steel, aluminium and copper. The discs are reinforced and very thin to make cutting easier and reduce effort during the operation.

Technical data:

• Type: thin cutting discs EZ SpeedClic

• Model: SC409

• Quantity: 5 discs

• Working diameter: 38.0 mm

• Shank diameter: 3.2 mm

• Max working depth: 14.0 mm

• Disc thickness: 0.75 mm (extra thin)

• Mounting system: EZ SpeedClic – quick tool-free change

• Maximum recommended speed: up to 35,000 rpm

• Material: fibreglass-reinforced abrasive (for long-lasting cuts)

• Use: cutting and parting of sheet metal and thin metal workpieces

The Dremel 432 is a set of abrasive bands (abrasive cylinders) for rotary tools, designed for sanding, shaping and surface cleaning on different materials. The 120 grit aluminium oxide coating offers a good balance between material removal and finish, making these bands ideal for surface preparation and finishing.

Technical data:

• Type: abrasive bands/cylinders for abrasion and sanding

• Model: 432

• Working diameter: approx. 13 mm (½″)

• Abrasive grit: 120 (medium/fine)

• Shank diameter: 3.2 mm (standard for rotary tools)

• Maximum operating speed: up to ~35 000 rpm

• Quantity: normally sold in packs of several pieces (e.g. 6 bands)

• Compatibility: Dremel-type rotary tools with 3.2 mm mandrel

Technical applications:

• Sanding and shaping of wood surfaces and plywood

• Rust removal and cleaning of metal surfaces

• Shaping and finishing of rubber, fibreglass and plastic

• Surface preparation before painting or other finishing

The Dremel 932 is an aluminium oxide grinding stone designed for grinding, deburring, weld deburring and material removal on metal surfaces, cast iron and other ferrous materials. It is compatible with rotary multi-tools fitted with a chuck that accepts 3.2 mm accessories.

Technical data:

• Type: aluminium oxide grinding stone

• Model: 932 (1 piece)

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm

• Material: aluminium oxide (durable abrasive)

• Shape: cylindrical / tapered for access to profiles and cavities

• Accessory length: approx. 40 mm

• Recommended maximum operating speed: up to 25,000 rpm

• Compatibility: rotary tools compatible with 3.2 mm accessories

Technical applications:

• Grinding of metal surfaces

• Deburring of welds and sharp edges

• Material removal in hard-to-reach areas

• Preparation of joints and surfaces for finishing

The Dremel 402 is a mandrel (screw pin) for rotary tools, designed for mounting cutting discs, polishing discs and other centre-hole accessories on Dremel multi-tools. It is one of the basic accessories required to use various discs and finishing wheels correctly with the tool.

Technical data:

• Type: mandrel / accessory mounting pin

• Model: 402

• Shank diameter: 3.2 mm (1/8″) – standard for Dremel rotary tools

• Material: hard-wearing metal

• Shape: pin with slotted screw head for tightening with a flat-blade key

• Maximum operating speed: up to 35 000 rpm

• Quantity: 4 pieces

• Compatibility: rotary multi-tools Dremel and other compatible with 3.2 mm chuck

Main features:

• Accessory fixing: allows you to mount cutting discs, polishing discs and other centre-hole accessories, holding them firmly in place during rotation.

• Slotted screw head: designed to be tightened or loosened with a flat-blade key or the key supplied with many Dremel kits, making accessory changes easier.

• Versatile use: compatible with a wide range of cutting and polishing accessories, including various Dremel cutting discs.

Technical applications:

• Mounting of abrasive cutting discs for operations on metal, wood and composite materials.

• Fixing of polishing discs or finishing wheels for removing micro-scratches or polishing.

• Use as a basic component for operations requiring centre-hole accessories on rotary multi-tools.

The Dremel 26150201JA is a set of replacement soldering tips designed for use with the Dremel VersaTip 2000 and VersaFlame 2200 gas torches/soldering irons. This accessory allows you to carry out precision soldering work, and to heat, melt or join thin metals and components in detail applications.

Technical data:

• Type: replacement soldering tips

• Model: 26150201JA

• Pack quantity: 2 pieces

• Tool compatibility: Dremel VersaTip 2000 and Dremel VersaFlame 2200 (gas soldering irons)

• Use: precision soldering on thin metals and small joints

• Tip material: heat-resistant metal

Technical applications:

• Soldering of small or thin metal components

• Detail repairs on metal objects

• DIY applications and finishing work with gas soldering irons

The Dremel 536 is a circular carbon steel brush designed for rotary tools, ideal for cleaning, rust removal, rough polishing and preparation of metal surfaces before finishing. The steel bristles give a more aggressive abrasive action than brass or nylon brushes, making the accessory suitable for ferrous metals and steels.

Technical data:

• Type: circular steel brush for cleaning and deburring

• Model: 536

• Working diameter: approx. 9.5 mm

• Shank diameter: 3.2 mm

• Bristle material: carbon steel

• Shape: circular “brush-type” brush

• Accessory length: approx. 45 mm

• Maximum operating speed: up to 15 000 – 20 000 rpm

• Compatibility: rotary tools with 3.2 mm chuck

Technical applications:

• Removal of rust, oxidation and flaking paint from metal surfaces

• Cleaning and preparation of ferrous metals before welding or coating

• Deburring of welded joints and sharp edges

• Rough polishing of metal before finer finishing

The Dremel Art. 636 is a drill bit set specifically for wood, designed for precision drilling in wood and similar materials with compatible rotary tools. Each bit features a centring point for a precise, straight start to the hole and a titanium coating for longer life and consistent performance.

Technical data:

• Type: wood drill bit set for rotary tools

• Model: 636

• Number of bits included: 4 pieces

• Working diameters: 3 mm, 4 mm, 5 mm, 6 mm

• Shank diameter: 3.2 mm (1/8″)

• Coating: titanium for long service life

• Centring point: yes, for accurate holes and a straight entry

• Recommended use: drilling in softwood, hardwood, laminate, plywood, chipboard and fibreboard

• Maximum recommended operating speed: up to 35 000 rpm

• Typical applications: precision drilling in wood, making holes from Ø 3 mm to Ø 6 mm, preparing joints, screw pilot holes and craft details

The Dremel 570 is a tungsten carbide removal bit designed for Dremel-type rotary tools, specifically for removing mortar or cement in the joints between tiles during renovation or maintenance work. It is used with the Dremel 568 accessory (grout removal attachment) to keep the bit centred between the joints and ensure controlled feed.

Technical data:

• Type: tungsten carbide grout / mortar removal bit

• Model: Item 570

• Working diameter: 3.2 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 58 mm

• Useful working length: approx. 10 mm

• Material: tungsten carbide

• Recommended maximum speed: up to 20,000 rpm (typical use 15–20 000 rpm)

• Compatibility: used with Dremel rotary tools and with the grout removal attachment (mod. 568) for removing mortar between tiles

Technical applications:

• Controlled removal of mortar or cement in the joints between tiles before replacing or repairing broken tiles.

• Preparing joints for regrouting or resealing.

The Dremel 9903 is a tungsten carbide engraving/carving cutter designed for rotary tools with a 3.2 mm shank, used to shape, smooth and remove material from hard surfaces with precision. This accessory is suitable for a wide range of applications on tough materials, delivering high performance even in demanding working conditions.

Technical data:

• Type: tungsten carbide engraving/carving cutter

• Model: 9903

• Shank diameter: 3.2 mm / 1/8″

• Working diameter: 3.2 mm

• Accessory length: approx. 39 mm

• Material: tungsten carbide (highly wear-resistant)

• Shape: rounded/cylindrical tip, ideal for engraving and material removal

• Maximum recommended speed: up to 30 000 rpm

• Compatibility: suitable for rotary tools with a chuck compatible with 3.2 mm accessories

Technical applications:
Engraving, shaping, material removal and detailing work on hard materials such as hardened steel, stainless steel, cast iron, ceramic, glass, plastic and hardwood.

The Dremel 7105 is a spherical diamond bit for rotary tools, designed for engraving, sculpting, shaping and material removal on hard or abrasive surfaces. This accessory has a coating of diamond particles that increase its resistance and effectiveness on materials that are difficult to work.

Technical data:

• Type: diamond bit for engraving / carving on hard materials

• Model: 7105

• Shank diameter: 3.2 mm

• Working diameter: 4.4 mm

• Accessory length: approx. 46 mm

• Material: steel with diamond coating for greater hardness and durability

• Shape: spherical bit / diamond disc

• Recommended operating speed: up to approx. 25 000–35 000 rpm (do not exceed the maximum values indicated)

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm chuck; does not require an additional chuck

Technical applications:

• Fine engraving and carving on glass, ceramic, porcelain, semi-precious stones

• Shaping and material removal on hardened and hard metals

• Detailed work on wood and other materials that are difficult to work with standard tools

Set of 6 EZ SpeedClic abrasive discs designed for sanding and shaping operations on surfaces and edges, with the EZ SpeedClic mounting system, which allows quick, tool-free replacement of accessories. The discs are suitable for relatively soft and medium-hard materials and are used with a compatible SpeedClic mandrel/mount.

Technical data:

• Type: EZ SpeedClic abrasive discs for sanding and shaping

• Model: SC411

• Working diameter: 30 mm

• Fitting diameter (shank): 3.2 mm

• Grit: 60 (medium abrasive)

• Quantity: 6 discs

• Mounting system: EZ SpeedClic – quick tool-free change

• Tool compatibility: compatible with Dremel SpeedClic chuck (e.g. SC402)

• Applications: sanding of flat surfaces and edges, material removal on wood, plastic, soft metals and other comparable materials
