DREMEL DIAMOND POINT FOR ENGRAVER

The Dremel 570 is a tungsten carbide removal bit designed for Dremel-type rotary tools, specifically for removing mortar or cement in the joints between tiles during renovation or maintenance work. It is used with the Dremel 568 accessory (grout removal attachment) to keep the bit centred between the joints and ensure controlled feed.

Technical data:

• Type: tungsten carbide grout / mortar removal bit

• Model: Item 570

• Working diameter: 3.2 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 58 mm

• Useful working length: approx. 10 mm

• Material: tungsten carbide

• Recommended maximum speed: up to 20,000 rpm (typical use 15–20 000 rpm)

• Compatibility: used with Dremel rotary tools and with the grout removal attachment (mod. 568) for removing mortar between tiles

Technical applications:

• Controlled removal of mortar or cement in the joints between tiles before replacing or repairing broken tiles.

• Preparing joints for regrouting or resealing.

Dremel Pack of 3 engraving cutters – item 110 is an engraving cutter/cutting engraving bit with a cylindrical head of approx. 1.9 mm, designed for detail work with high-speed rotary tools. It is suitable for shaping, engraving, grooving and material removal on various materials, offering precision even on curved surfaces.

Technical data:

• Type: engraving cutter / engraving bit

• Model: 110 / 26150110JA

• Working diameter: ~1.9 mm (5/64 in)

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~45 mm

• Material: high-speed steel

• Maximum recommended operating speed: up to approx. 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Pack quantity:

• 1 engraving cutter

Technical applications:

• Engraving and material removal on wood, plastic, laminates, soft metals and similar materials

• Creation of grooves, profiles, hollowing and precision details

• Can also be used on curved or hard-to-reach surfaces

The Dremel 455 accessory is an aluminium oxide abrasive wheel designed to quickly sharpen the teeth of chainsaw chains using compatible rotary tools. This accessory is intended to be used together with the Dremel chainsaw sharpening kit or standalone to restore the sharpness of chains, increasing efficiency and service life.

Technical data:

• Type: abrasive wheels for saw chain sharpening

• Model: 455

• Working diameter: ~5.6 mm

• Shank diameter: 3.2 mm

• Abrasive material: aluminium oxide

• Shape: cylindrical

• Accessory length: approx. 50 mm

• Recommended maximum operating speed: up to 30 000 rpm

• Quantity: sets of multiple wheels available in variants (with/without spacers)

• Compatibility: rotary tools with 3.2 mm chuck and chain sharpening accessories

Technical applications:

• Sharpening the teeth of the chain of chainsaws with precision and control, guiding the tool in line with the recommended sharpening angles.

• Use with guides and spacers to improve results and keep the teeth uniform.

The Dremel 2615MS52JA is a set of 5 fine-tooth serrated blades for the Dremel Moto‑Saw (MS20) jigsaw, designed for detailed and precise cuts in wood and similar materials such as plastic or laminates. The blades have a profile with 7 teeth per centimetre to ensure clean, controlled cuts, even in curves and complex profiles.

Technical data:

• Type: serrated blades for jigsaw

• Model: 2615MS52JA

• Compatibility: Dremel Moto‑Saw (MS20‑1/5)

• Quantity per pack: 5 pieces

• Blade diameter / thickness: 0.2 mm

• Overall length: 100 mm

• Cutting depth: 12 mm

• Number of teeth: 7 teeth/cm (≈ fine grain)

• Material applications: softwood and hardwood, plywood, laminates, plastic and similar soft materials

Technical applications:

• Precise, controlled cutting of wood and boards

• Creating curves, profiles and details in light materials

• Shaping and finishing work on plastic materials

The Dremel 2615MS53JA is a set of serrated blades for cutting metal for use with the Dremel Moto‑Saw (MS20) jigsaw. The blades are specifically designed for cutting light sheet metal and soft metal, ensuring precision and control on both curved and straight profiles.

Technical data:

• Type: blades for Moto‑Saw jigsaw

• Model: 2615MS53JA

• Application: cutting soft metal/light sheet metal

• Total blade length: 100 mm

• Cutting depth: 3 mm

• Number of teeth: 10 teeth per centimetre

• Blade thickness: approx. 0.2 mm

• Compatibility: Dremel Moto‑Saw (MS20‑1/5) and other Moto‑Saw jigsaws that accept MS53 blades

Package contents:

• 5 × MS53 serrated metal-cutting blades (5 pieces)

Technical applications:

• Cutting sheet metal and soft metal sheets

• Making curved and straight cuts in thin metallic materials

• Suitable for metals such as aluminium, copper, brass and similar

The item 192 is a 4.8 mm high-speed tapered cutter (carving/engraving bit) for rotary tools, designed for shaping, engraving and removing material in precision work on wood, plastic and similar materials. Ideal for creating grooves, profiles, hollows and small tapered holes on flat or curved surfaces.

Technical data:

• Type: high-speed tapered carving/engraving cutter

• Model: 192 / 26150192JA

• Working diameter: 4.8 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~38 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Quantity in the pack:

• 2 × item 192

Technical applications:

• Shaping and engraving of wood, plastic, laminates and similar materials

• Creation of grooves, profiles, hollows and small tapered holes

• Detail work and decoration on soft materials

The Dremel 615 is a high-speed steel (HSS) router bit designed for compatible rotary tools, intended for rounding edges and chamfering corners on wood or similar materials. This accessory is ideal for decorative work, profile finishing and detail cuts on wood and soft materials.

Technical data:

• Type: router bit / bit for rounding corners on wood and soft materials

• Model: Item 615

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm

• Total accessory length: approx. 37 mm

• Material: high-speed steel (HSS)

• Recommended maximum operating speed: up to 35 000 rpm

• Guide pin: present, for stability and cutting precision

• Tool compatibility: Dremel rotary multi-tools with a 3.2 mm chuck or router attachment (e.g. 231 or 335)

Technical applications:

• Rounding and chamfering of edges and corners on wood

• Decorative cuts and finishing on panels and edges

• Detail work on soft materials such as wood, plywood, laminates, plastic and perspex

The Dremel 7103 is a 2 mm diamond ball bit for rotary tools, designed for engraving, carving and precision detail work on particularly hard or tough materials. The coating of diamond particles gives greater surface hardness and better performance than traditional abrasive accessories, making it suitable for many finishing applications.

Technical data:

• Type: diamond ball bit for engraving/carving

• Model: 7103

• Working diameter: 2.0 mm

• Shank diameter: 3.2 mm

• Accessory length: 45.0 mm

• Material: steel with diamond coating

• Shape: spherical → allows concave engraving, grooves and detailed relief work

• Recommended maximum operating speed: up to approx. 25 000 rpm

• Quantity: set of 2 diamond bits

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm accessory chuck

Typical applications:

• Precision engraving and carving on glass, ceramic and porcelain

• Shaping and touching up on hardened metal and wood

• Detail work on hard and brittle materials

• Finishing and decorating work for hobbyists and professional projects

The Dremel 8215 is an aluminium oxide grinding stone designed for grinding, deburring and sharpening on metals and other hard surfaces. The cylindrical shape and large diameter make this accessory suitable for general work, burr removal, smoothing welded joints and finishing on tapered or flat surfaces.

Technical data:

• Type: aluminium oxide grinding stone for general grinding, deburring and sharpening

• Model: 8215

• Working diameter: 25.4 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 40 mm

• Abrasive material: aluminium oxide

• Shape: cylindrical

• Recommended maximum operating speed: up to approx. 20 000 rpm (varies depending on the material)

• Compatibility: rotary tools fitted with a chuck for 3.2 mm accessories (Dremel series and compatible tools)

Technical applications: smoothing, deburring and sharpening of metals, removal of burrs from castings, smoothing welded joints, removal of rivets and rust.

The item 115 is a cylindrical high-speed cutter of approximately 7.8 mm, designed for carving, engraving and removing material on a variety of surfaces. It is designed to achieve precision machining in operations such as shaping, engraving, grooving and tapered drilling with high-speed rotary tools.

Technical data:

• Type: high-speed cylindrical carving/engraving cutter

• Model: 115 / 26150115JA

• Working diameter: approx. 7.9 mm (5/16 in)

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: approx. 38 mm

• Material: high-speed steel

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm chuck

• Recommended speed: up to approx. 30 000 rpm, varying according to the material being worked (wood, plastic, soft metal)

Quantity in the pack:

• 2 × carving/engraving bits (cylindrical shape) included in the standard 115 pack.

Technical applications:

• Shaping and removal of material on wood, plastic and soft metals

• Engraving, grooving and creation of profiles on flat or curved surfaces

• Creation of tapered holes and precision details in material machining projects

The Dremel 723 is a complete 100-piece multi-purpose accessory set designed for use with Dremel rotary multi-tools and other compatible tools with a 3.2 mm chuck. This kit of genuine accessories offers a wide range of components for cutting, sanding, grinding, polishing, cleaning and milling on materials such as wood, metal, plastic and more, making it ideal for DIY projects, workshop use and precision work (also ideal as a starter kit for getting started with the rotary tool).

• Detailed contents – Dremel 723 (100 pieces)

  Mandrels and basic bits

  • 1 × drill bit 150

  • 1 × screw mandrel 401

  • 1 × screw mandrel 402

  • 1 × EZ SpeedClic SC402 mandrel for SpeedClic discs

  Milling / Engraving

  • 1 × high-speed cutter 191

  Grinding stones

  • 1 × aluminium oxide grinding stone Ø 9.5 mm 932

  • 1 × aluminium oxide grinding stone Ø 9.5 mm 952

  • 1 × silicon carbide grinding stone Ø 4.8 mm 84922

  Cutting / grinding wheels and discs

  • 36 × cutting discs Ø 24 mm 409

  • 3 × EZ SpeedClic cutting discs for metal (SC456)

  • 10 × abrasive discs Ø 38 mm 411

  • 8 × abrasive discs Ø 38 mm 413

  Sanding / grinding with bands

  • 1 × sanding band mandrel Ø 6.4 mm + band 430

  • 4 × bands Ø 6.4 mm grit 60 431

  • 4 × bands Ø 6.4 mm grit 120 438

  • 1 × sanding band mandrel Ø 13 mm 407

  • 3 × bands Ø 13 mm grit 60 408

  • 4 × bands Ø 13 mm grit 120 432

  Cleaning / polishing

  • 10 × polishing wheels Ø 13 mm 414

  • 5 × polishing wheels Ø 26 mm 429

  • 1 × bristle brush Ø 19 mm 403

  • 1 × polishing compound 421

  Milling, engraving and detailed work

The Dremel 454 is an aluminium oxide abrasive grinding wheel designed for use with Dremel-type rotary multi-tools, specifically for sharpening the teeth of saw chains, guides and metal profiles. Thanks to its compact diameter and sturdy construction, it allows you to restore the angle and sharpness of the chain teeth with control and precision.

Technical data:

• Type: abrasive grinding wheel for sharpening saw chains

• Model: 454

• Working diameter: approx. 4.8 mm

• Shank diameter: 3.2 mm (standard multi-tool)

• Abrasive material: aluminium oxide

• Shape: cylindrical / for contact with the chain profile

• Accessory length: approx. 50 mm

• Maximum operating speed: up to 30 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm chuck

Technical applications:

• Sharpening of chainsaw chain teeth to restore sharpness and cutting performance.

• Use with sharpening guides or spacers to maintain consistent angles between the teeth.

• Preparing the chain for cleaner and safer cuts.

The Dremel SC 407 is an EZ SpeedClic sanding set consisting of a mandrel with a quick-change system and two 13 mm sanding bands of different grits, designed for sanding, shaping and material removal on wood, plastic, soft metals and other materials. The EZ SpeedClic™ system allows accessories to be changed without the use of spanners, making use quicker and more intuitive.

Technical data:

• Type: EZ SpeedClic mandrel + sanding bands for sanding

• Model: SC 407

• Shank diameter: 3.2 mm

• Band working diameter: 13.0 mm

• Abrasive material: aluminium oxide

• Grits included: 60 (more aggressive) and 120 (finer)

• Compatibility: rotary tools with 3.2 mm chuck and EZ SpeedClic™ system

• Recommended operating speed: up to 35 000 rpm

• Mounting system: EZ SpeedClic™ — tool-free accessory change

Exact package contents:

• 1 × EZ SpeedClic sanding mandrel

• 1 × 13 mm sanding band, grit 60 (very aggressive)

• 1 × 13 mm sanding band, grit 120 (finer)

Technical applications:

• Sanding and material removal on softwood and hardwood

• Roughing and finishing on plastics and composite materials

• Cleaning and removal of light oxidation from soft metals

• Contouring and surface preparation before finishing

The Dremel 537 accessory is a brass brush for rotary tools designed for cleaning and surface finishing of relatively soft and delicate metals, ideal for removing oxidation and residues and for creating a satin or matt finish without scratching the surface. The brass bristles are non‑sparking and softer than steel, reducing the risk of damaging sensitive materials.

Technical data:

• Type: brass brush for cleaning/polishing

• Model: 537

• Shank diameter: 3.2 mm

• Working diameter: 3.2 mm

• Bristle material: brass (wire brass)

• Shape: rotary brush

• Accessory length: approx. 48 mm

• Maximum operating speed: 15 000 rpm

• Compatibility: rotary tools with 3.2 mm shank (Dremel and compatible)

Technical applications:

• Cleaning of soft metal surfaces such as gold, bronze, copper and brass without generating sparks

• Surface finishing to achieve a satin or matt effect

• Removal of oxidation and residues from joints or hard-to-reach points

• Surface preparation before further machining or fine polishing

The Dremel 422 is a felt polishing bit for rotary tools, designed for the polishing and surface finishing of metals, plastics and other materials. Its compact profile and felt construction also make it suitable for cleaning details, holes or hard-to-reach surfaces, and it can be used with or without polishing compound to obtain a smooth, shiny surface.

Technical data:

• Type: felt polishing bit/cylinder for rotary tools

• Model: Art. 422

• Working diameter: 10 mm

• Shank diameter: 3.2 mm (standard mandrel)

• Material: abrasive polishing felt

• Shape: polishing cone/cylinder

• Recommended maximum operating speed: up to 20 000 rpm

• Compatibility: Dremel type rotary tools with a 3.2 mm chuck (use with a suitable pin/clamp)

Technical applications:

• Polishing of ferrous and non-ferrous metals (steel, brass, aluminium, silver, etc.)

• Finishing and polishing of plastics and perspex after abrasive operations

• Cleaning of details, corners and holes thanks to the conical shape

• Use with or without polishing compound/paste to obtain different finishes
