DREMEL ACCESSORY TR 408 (4 CYLINDERS)

The Dremel 401 is a mandrel (screw pin) for rotary tools, designed for mounting and securing polishing and cleaning accessories on Dremel multi-tools. It is particularly suitable for use with felt wheels and other accessories intended for finishing.

Technical data:

• Type: mandrel / accessory mounting pin

• Model: 401

• Shank diameter: 3.2 mm (≈ 1⁄8″) standard for rotary tools

• Total length: approx. 39 mm

• Material: wear-resistant metal

• Shape: screw pin with threaded head for mounting accessories

• Maximum operating speed: up to 35 000 rpm

• Pack quantity: 3 pieces

• Compatibility: Dremel-type rotary tools and multi-tools with 3.2 mm chuck

Main features:

• Ergonomic mounting: threaded head that allows accessories such as felt wheels and polishing bits to be screwed on directly.

• Ease of use: robust and intuitive design for a quick accessory change.

• Versatility: used mainly with accessories intended for polishing and finishing.

Technical applications:

• Securing felt polishing wheels (e.g. models 414, 422, 429) for bright finishes on metals and plastics.

• Mounting polishing bits for surface finishing and precision in detail work.

The Dremel Art. 425 is a pressed felt polishing disc designed for rotary tools, ideal for achieving glossy, refined finishes on metals and plastic materials. It is intended for use with polishing compound and other polishing discs to obtain a brilliant result on machined surfaces.

Technical data:

• Type: felt polishing disc for rotary tools

• Model: Art. 425

• Working diameter: 22.5 mm (≈ 2.25 cm)

• Shank diameter: 3.2 mm (standard mandrel)

• Material: abrasive polishing felt

• Shape: circular disc

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

• Recommended maximum operating speed: up to approx. 20 000 rpm

• Mounting: by means of a mandrel/clamp suitable for polishing wheels

Technical applications:

• Polishing of metal surfaces such as steel, brass, copper, aluminium and stainless steel for a brilliant effect.

• Surface finishing of hard plastics after grinding and sanding.

• Use with polishing compound to obtain a higher level of shine on machined surfaces.

The Dremel 532 is a circular steel brush for rotary tools designed for cleaning, deburring and removal of rust or oxidation from metal surfaces and mechanical parts. The compact construction and steel bristles provide effective abrasive cleaning while maintaining good precision on fine detail.

Technical data:

• Type: circular steel brush for cleaning/deburring

• Model: 532

• Working diameter: approx. 9.5 mm

• Shank diameter: 3.2 mm (multi-tool standard)

• Bristle material: steel

• Shape: circular “brush-type” brush

• Overall accessory length: approx. 45 mm

• Recommended maximum operating speed: up to 15 000 – 20 000 rpm

• Compatibility: rotary tools with 3.2 mm chuck

Typical applications:

• Removal of rust, flaking paint and scale from metal

• Cleaning of metal surfaces before finishing or protection

• Deburring of cuts, edges and joints

• Surface preparation for welding or coatings

The Dremel 26159924JA, also identified as accessory 9924, is a precision carbide engraving bit designed for use with the Dremel 290 engraver and other compatible rotary tools with standard shank bits. It is designed for decorative or technical engraving on a variety of surfaces, maintaining control and detail when producing lines and grooves.

Technical data:

• Type: engraving bit / carbide engraving bit

• Model: 9924 – 26159924JA

• Bit material: carbide (tungsten)

• Tool compatibility: Dremel 290 engraver and other rotary tools that accept engraving accessories

• Bit diameter: approx. 3 mm

• Overall length: approx. 22 mm

• Use: engraving of fine lines and grooves on various materials such as metal, glass, wood, plastic, ceramic and leather

• Quantity per pack: 3 engraving bits (code 9924 / 26159924JA)

Technical applications:

• Making decorative or functional engravings on hard or soft surfaces

• Creating precise grooves, outlines and details on mixed materials

The Dremel 462 is an impregnated rubber polishing point, designed for use with rotary multi-tools. This accessory is intended to remove light scratches, burrs and machining marks on ferrous metals and other materials, giving a smoother finish after grinding or sanding operations.

Technical data:

• Type: rubber point for polishing and finishing

• Model: Item 462

• Working diameter: approx. 6.4 mm

• Shank diameter: 3.2 mm

• Overall length: approx. 51 mm

• Material: rubber impregnated with polishing abrasive

• Recommended maximum operating speed: up to 30 000 rpm

• Quantity: 1 piece (variants and kits with several points available)

• Shape: conical/cylindrical for detail work and flat surfaces

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm chuck

Technical applications:

• Removal of machining scratches on ferrous metal surfaces

• Polishing and finishing of metal and similar materials after material removal

• Cleaning of grooves and hard-to-reach details

The Dremel 426 is a fibreglass-reinforced abrasive cutting disc for rotary tools, designed for straight cuts and slots in metal and a variety of other materials. It offers greater strength and durability than basic discs, making it suitable also for harder metals and heavy-duty use compared with standard discs.

Technical data:

• Type: fibre-reinforced abrasive cutting disc

• Model: Art. 426

• Quantity: packs available of 1 or 5 discs (variants available)

• Working diameter: 32 mm

• Disc thickness: approx. 1.1 mm

• Shank diameter: 3.2 mm (standard mandrel)

• Abrasive material: aluminium oxide with fibreglass reinforcement

• Maximum operating speed: up to 35 000 rpm

• Max cutting depth: approx. 14 mm

• Mounting: with screw mandrel (pin) type 402

• Use: cutting along the edge only of the disc

Workable materials:

• Ferrous and non-ferrous metals, including hardened steel, aluminium, copper, brass, stainless steel

• Thin wood, plastic, plasterboard, light marble and brick (short cuts)

Technical applications:

• Making straight cuts and slots in metal, sheet metal and sections

• Cutting bolts, screws or metal bars with control and precision

• Cuts in composite or plastic materials during repair or modification work

The item 115 is a cylindrical high-speed cutter of approximately 7.8 mm, designed for carving, engraving and removing material on a variety of surfaces. It is designed to achieve precision machining in operations such as shaping, engraving, grooving and tapered drilling with high-speed rotary tools.

Technical data:

• Type: high-speed cylindrical carving/engraving cutter

• Model: 115 / 26150115JA

• Working diameter: approx. 7.9 mm (5/16 in)

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: approx. 38 mm

• Material: high-speed steel

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm chuck

• Recommended speed: up to approx. 30 000 rpm, varying according to the material being worked (wood, plastic, soft metal)

Quantity in the pack:

• 2 × carving/engraving bits (cylindrical shape) included in the standard 115 pack.

Technical applications:

• Shaping and removal of material on wood, plastic and soft metals

• Engraving, grooving and creation of profiles on flat or curved surfaces

• Creation of tapered holes and precision details in material machining projects

The Dremel 2615MS51JA is a set of multi-purpose blades for the Dremel Moto‑Saw (MS20) jigsaw, designed for straight and curved cuts in wood and plastic. The blades, with 6 teeth per centimetre, offer a good compromise between feed speed and cutting precision, making them suitable for general cutting of light to medium materials.

Technical data:

• Type: serrated blades for Moto‑Saw jigsaw

• Model: 2615MS51JA

• Compatibility: Dremel Moto‑Saw (MS20‑1/5)

• Quantity per pack: 5 pieces

• Overall blade length: 100 mm

• Cutting depth: 18 mm

• Teeth per centimetre: 6 TPI (≈ 6 teeth/cm)

• Blade width: 4.0 mm

• Blade thickness: 0.4 mm

• Blade depth: 2.5 mm

Technical applications:

• Straight and curved cutting in softwood and hardwood, chipboard, laminates and plywood.

• Cutting and finishing of plastic and similar materials for profiling or joints.

The Dremel 640 is a high-speed steel (HSS) router bit of 6.4 mm designed for rotary tools, ideal for V-grooves, decorative engraving and carving, especially in light or soft materials such as wood, plywood, laminates and plastic. It is also particularly suitable for decoration and finishing details and can be used with dedicated router/plunge accessories to optimise the depth of cut.

Technical data:

• Type: router bit for V-grooves in wood and soft materials

• Model: Art. 640

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm (compatible with standard chucks)

• Accessory length: approx. 37 mm

• Effective working length: approx. 2.0 mm

• Material: high-speed steel (HSS)

• Recommended operating speed: up to 35 000 rpm

• Compatibility: rotary multi-tools with 3.2 mm chuck, including use with the Dremel router/plunge attachment for greater depth control.

Technical applications:

• Cutting V-grooves in wood and similar materials

• Engraving shapes, lettering or decorative profiles

• Inlay work and finishing on panels and composite surfaces

The Dremel 615 is a high-speed steel (HSS) router bit designed for compatible rotary tools, intended for rounding edges and chamfering corners on wood or similar materials. This accessory is ideal for decorative work, profile finishing and detail cuts on wood and soft materials.

Technical data:

• Type: router bit / bit for rounding corners on wood and soft materials

• Model: Item 615

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm

• Total accessory length: approx. 37 mm

• Material: high-speed steel (HSS)

• Recommended maximum operating speed: up to 35 000 rpm

• Guide pin: present, for stability and cutting precision

• Tool compatibility: Dremel rotary multi-tools with a 3.2 mm chuck or router attachment (e.g. 231 or 335)

Technical applications:

• Rounding and chamfering of edges and corners on wood

• Decorative cuts and finishing on panels and edges

• Detail work on soft materials such as wood, plywood, laminates, plastic and perspex

The item 192 is a 4.8 mm high-speed tapered cutter (carving/engraving bit) for rotary tools, designed for shaping, engraving and removing material in precision work on wood, plastic and similar materials. Ideal for creating grooves, profiles, hollows and small tapered holes on flat or curved surfaces.

Technical data:

• Type: high-speed tapered carving/engraving cutter

• Model: 192 / 26150192JA

• Working diameter: 4.8 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~38 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Quantity in the pack:

• 2 × item 192

Technical applications:

• Shaping and engraving of wood, plastic, laminates and similar materials

• Creation of grooves, profiles, hollows and small tapered holes

• Detail work and decoration on soft materials

The Dremel 84922JA is a set of silicon carbide abrasive points for rotary tools with a standard 3.2 mm shank. These small conical points are designed for grinding, deburring and engraving on hard or non-ferrous materials where traditional aluminium oxide points are less effective.

Technical data:

• Type: silicon carbide abrasive points for grinding and deburring

• Model: 84922JA

• Pack quantity: set of 3 pieces

• Working diameter: 4.8 mm

• Shank diameter: 3.2 mm

• Shape: small cone for access to surfaces and details

• Abrasive material: silicon carbide, more durable than aluminium oxide points

• Accessory length: approx. 40 mm

• Recommended maximum operating speed: up to 25 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a chuck for 3.2 mm accessories

Technical applications:

• Grinding and deburring of hard and brittle materials such as glass, ceramic, porcelain, stone and non-ferrous metals

• Engraving and material removal on uneven surfaces

• Preparation of complex surfaces before finishing

The Dremel 569 is a tungsten carbide removal bit designed for Dremel-type rotary tools, specifically for removing mortar or grout from the joints between tiles during renovation or maintenance work. It is intended for spot use or small repairs in combination with the dedicated grout removal attachment (model 568) to keep the bit centred and ensure controlled feed of the tool.

Technical data:

• Type: tungsten carbide grout / mortar removal bit

• Model: 569

• Working diameter: ~1.6 mm (≈ 1⁄16″)

• Shank diameter: 3.2 mm (≈ 1⁄8″), compatible with Dremel rotary tools

• Accessory length: approx. 58 mm

• Material: tungsten carbide

• Recommended operating speed: 15 000 – 20 000 rpm (use with guide and slow feed)

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm shank; can be used with the grout removal attachment 568 to remove grout between tiles

Technical applications:

• Controlled removal of mortar or grout from the joints between tiles before regrouting or resealing

• Preparing tile joints for maintenance or replacement

• Use with a guide/fixing to keep the bit aligned between the tiles

The Dremel Art. 420 is a heavy duty abrasive cutting disc for rotary tools, designed for straight cuts in metal and other materials with greater strength and durability than standard cutting discs. It is suitable both for heavy-duty applications on ferrous materials and for work on wood, plastic and light building materials.

Technical data:

• Type: heavy duty abrasive cutting disc

• Model: Art. 420

• Working diameter: 24.0 mm (≈ 0,94")

• Disc thickness: ≈ 1.0 mm

• Shank diameter: 3.2 mm (standard mandrel)

• Abrasive material: reinforced aluminium oxide

• Shape: disc with cutting along the edge

• Maximum operating speed: up to 35 000 rpm

• Mounting: with 402 screw mandrel

• Quantity: typically 1 piece

Technical applications:

• Straight cutting of ferrous and non-ferrous metals, including bars, sheet and tubes.

• Sectioning of bolts, screws and profiles.

• Cutting of thin wood, plastic, panels and composite materials.

The Dremel 7105 is a spherical diamond bit for rotary tools, designed for engraving, sculpting, shaping and material removal on hard or abrasive surfaces. This accessory has a coating of diamond particles that increase its resistance and effectiveness on materials that are difficult to work.

Technical data:

• Type: diamond bit for engraving / carving on hard materials

• Model: 7105

• Shank diameter: 3.2 mm

• Working diameter: 4.4 mm

• Accessory length: approx. 46 mm

• Material: steel with diamond coating for greater hardness and durability

• Shape: spherical bit / diamond disc

• Recommended operating speed: up to approx. 25 000–35 000 rpm (do not exceed the maximum values indicated)

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm chuck; does not require an additional chuck

Technical applications:

• Fine engraving and carving on glass, ceramic, porcelain, semi-precious stones

• Shaping and material removal on hardened and hard metals

• Detailed work on wood and other materials that are difficult to work with standard tools

Dremel 108 engraving cutter is an engraving cutter/engraving bit with a cylindrical shape, 0.8 mm, designed for detail work with high-speed rotary tools. This tool allows you to carve, engrave, mill and create grooves with precision on materials such as wood, plastic, leather, rubber and soft metals, and is also suitable for curved or complex surfaces.

Technical data:

• Type: engraving cutter / engraving bit

• Model: 108 / 26150108JA

• Working diameter: 0.8 mm (approx. 1/32 in)

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: approx. 45 mm

• Material: high-speed steel / hardened steel for general use

• Maximum recommended operating speed: up to approx. 35 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm chuck

Pack quantity:

• 3 × engraving cutters 0.8 mm

Technical applications:

• Engraving, shaping and material removal on wood, plastic, laminates, fibreglass and soft metals

• Creation of grooves, profiles, tapered holes and details on flat or curved surfaces

• Ideal for precision work, decoration and artistic carving on soft materials
