DREMEL ACCESSORY (CHUCK) 4486

Single tungsten carbide cutter with a ball tip for rotary tools, designed for engraving, shaping and material removal on hard surfaces.
The spherical tip geometry allows concave channels, curves and rounded details to be produced with control and precision on a wide range of materials, including metal and difficult-to-machine materials.

Technical data:

• Type: tungsten carbide cutter for engraving/shaping

• Model: Art. 9905

• Shank diameter: 3.2 mm

• Working diameter: 3.2 mm

• Accessory length: 38.0 mm (approx.)

• Material: tungsten carbide (C‑2)

• Tip shape: spherical (ball tip)

• Maximum recommended operating speed: up to 30 000 rpm

Technical applications:
Engraving, shaping of concave profiles, material removal and fine detailing on hardened steel, stainless steel, cast iron, ceramic, non-ferrous metals, hardwood or plastic.

The Dremel 7120 is an oval disc diamond abrasive bit designed for Dremel-type rotary tools, specifically for engraving, shaping and removing material on hard or fragile surfaces. It is particularly suitable when precision work is needed on resistant materials such as glass, ceramic or hardened metal, where a traditional cutter would perform less well or wear out quickly.

Technical data:

• Accessory type: diamond bit / abrasive disc for finely detailed engraving and shaping

• Model: 7120

• Working diameter: approx. 6.7 mm

• Shank diameter: 2.4 mm (3/32″) standard Dremel

• Shape: oval diamond disc

• Material: steel with diamond coating

• Maximum recommended speed: up to 25 000 rpm (in some references up to 35 000 rpm)

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm accessory chuck

Technical applications:

• Engraving and shaping of hard surfaces such as glass, ceramic, porcelain

• Detail work on hardened metal and hard steels

• Precision work on thin materials or materials that are difficult to section

• Material removal with greater control than conventional abrasives

The Dremel 482 is a clamping collet for Dremel rotary tools, designed to hold securely bits and accessories with a thin 1.6 mm (≈ 1/16") shank. This type of collet ensures a secure grip of the accessory in the chuck, improving precision and stability during drilling, milling, engraving or other detail operations. It is part of the range of interchangeable collets used to adapt the tool to different accessory diameters.

Technical data:

• Type: clamping collet for rotary tools

• Model: Item 482

• Supported shank diameter: 1.6 mm (≈ 1/16″) (for accessories with a thin shank)

• Material: hard-wearing metal for a secure grip

• Compatibility: Dremel rotary tools with standard chuck (including use with flexible shaft)

• Use: secures the accessory in the chuck for precision work

• Installation: fits into the chuck and is tightened with the multi-tool's clamping nut

Technical applications:

• Holding 1.6 mm bits for drilling, engraving, milling or sanding on materials such as wood, metal or plastic.

• Improves stability and control in detail and precision applications.

The Dremel 640 is a high-speed steel (HSS) router bit of 6.4 mm designed for rotary tools, ideal for V-grooves, decorative engraving and carving, especially in light or soft materials such as wood, plywood, laminates and plastic. It is also particularly suitable for decoration and finishing details and can be used with dedicated router/plunge accessories to optimise the depth of cut.

Technical data:

• Type: router bit for V-grooves in wood and soft materials

• Model: Art. 640

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm (compatible with standard chucks)

• Accessory length: approx. 37 mm

• Effective working length: approx. 2.0 mm

• Material: high-speed steel (HSS)

• Recommended operating speed: up to 35 000 rpm

• Compatibility: rotary multi-tools with 3.2 mm chuck, including use with the Dremel router/plunge attachment for greater depth control.

Technical applications:

• Cutting V-grooves in wood and similar materials

• Engraving shapes, lettering or decorative profiles

• Inlay work and finishing on panels and composite surfaces

The Dremel 8215 is an aluminium oxide grinding stone designed for grinding, deburring and sharpening on metals and other hard surfaces. The cylindrical shape and large diameter make this accessory suitable for general work, burr removal, smoothing welded joints and finishing on tapered or flat surfaces.

Technical data:

• Type: aluminium oxide grinding stone for general grinding, deburring and sharpening

• Model: 8215

• Working diameter: 25.4 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 40 mm

• Abrasive material: aluminium oxide

• Shape: cylindrical

• Recommended maximum operating speed: up to approx. 20 000 rpm (varies depending on the material)

• Compatibility: rotary tools fitted with a chuck for 3.2 mm accessories (Dremel series and compatible tools)

Technical applications: smoothing, deburring and sharpening of metals, removal of burrs from castings, smoothing welded joints, removal of rivets and rust.

The Dremel 670 is a mini circular saw to attach to a Dremel rotary multi-tool, designed to make clean, straight cuts in wood and wood-like materials. It turns your multi-tool into a small portable saw with an integrated directional guide and a transparent guard for better visibility while cutting.

Technical data:

• Type: mini circular saw attachment for multi-tool

• Compatibility: suitable for Dremel models and other rotary tools compatible with the quick connect system

• Standard blade included: mini circular blade Ø 31.8 mm

• Maximum cutting depth: 6.35 mm

• Structure: angled base for perpendicular cuts with directional guide

• Transparent guard for visibility of the cutting area

• Attachment length: approx. 50 mm

• Overall width: approx. 90 mm

• Overall depth: approx. 45 mm

• Use: thin, precise cuts in wood, laminates and similar materials

The Dremel 2615MS51JA is a set of multi-purpose blades for the Dremel Moto‑Saw (MS20) jigsaw, designed for straight and curved cuts in wood and plastic. The blades, with 6 teeth per centimetre, offer a good compromise between feed speed and cutting precision, making them suitable for general cutting of light to medium materials.

Technical data:

• Type: serrated blades for Moto‑Saw jigsaw

• Model: 2615MS51JA

• Compatibility: Dremel Moto‑Saw (MS20‑1/5)

• Quantity per pack: 5 pieces

• Overall blade length: 100 mm

• Cutting depth: 18 mm

• Teeth per centimetre: 6 TPI (≈ 6 teeth/cm)

• Blade width: 4.0 mm

• Blade thickness: 0.4 mm

• Blade depth: 2.5 mm

Technical applications:

• Straight and curved cutting in softwood and hardwood, chipboard, laminates and plywood.

• Cutting and finishing of plastic and similar materials for profiling or joints.

The Dremel 540 is a set of universal cutting discs for rotary multi-tools, designed mainly for straight cutting of metal and also suitable for wood, plastic, light masonry and composite materials. The discs cut along the edge only and are to be fitted to the tool with the 402 screw mandrel.

Technical data:

• Type: cutting discs for rotary multi-tool

• Model: 540

• Quantity: set of 5 pieces

• Working diameter: 32.0 mm

• Disc thickness: 1.6 mm (typical)

• Shank diameter: 3.2 mm

• Max. cutting depth: 14.0 mm

• Maximum operating speed: ≤ 35 000 rpm

• Shape: thin disc

• Fixing: with 402 screw mandrel

Workable materials: metal (steel, stainless steel, aluminium, copper, brass), sheet metal, bolts/screws, plastic, thin wood, panels, plasterboard and light building materials.

Technical applications:

• Making straight cuts in metal and thin materials

• Cutting bolts, screws and sheet metal without the need for larger tools

• Sectioning plastic materials and light panels with control

The Dremel 199 is a high-speed cutter (carving/engraving bit) of 9.5 mm for rotary tools, designed for carving, engraving, grooving and material removal in detail work on various materials. It is a versatile accessory for shaping, creating profiles and grooves or making tapered holes, ideal for precision work.

Technical data:

• Type: high-speed cutter for carving/engraving

• Model: 199 / 26150199JA

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~39 mm

• Material: high-speed steel (High Speed Steel)

• Recommended maximum operating speed: up to ~30 000 – 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm chuck

Pack quantity:

• 1 × Dremel 199 cutter

Technical applications:

• Shaping and carving of wood, plastic, laminates and similar materials

• Creating grooves, profiles, hollows and tapered holes on flat or curved surfaces

• Engraving and decoration on soft materials

The Dremel 542 is a carbide cutting and shaping disc for rotary tools, designed specifically for cutting, shaping and sanding wood and similar materials such as laminates and fibreboard. The carbide coating ensures longer life and wear resistance when working on hard or soft wood, and also allows grooves and profiles to be made with precision.

Technical data:

• Type: cutting/shaping disc for wood with carbide coating

• Model: Item 542

• Working diameter: 25.4 mm

• Shank diameter: 3.2 mm

• Max. cutting depth: 9.0 mm

• Maximum recommended speed: up to 35 000 rpm

• Workable materials: hard and soft wood, chipboard, plywood, laminates and wood fibreboard

• Compatibility: Dremel rotary tools with 3.2 mm shank

• Pack quantity: 1 disc

Technical applications:

• Cutting and sectioning of wood and wood panels

• Shaping and creating grooves in wooden materials

• Light sanding while cutting thanks to the abrasive carbide coating

The Dremel 401 is a mandrel (screw pin) for rotary tools, designed for mounting and securing polishing and cleaning accessories on Dremel multi-tools. It is particularly suitable for use with felt wheels and other accessories intended for finishing.

Technical data:

• Type: mandrel / accessory mounting pin

• Model: 401

• Shank diameter: 3.2 mm (≈ 1⁄8″) standard for rotary tools

• Total length: approx. 39 mm

• Material: wear-resistant metal

• Shape: screw pin with threaded head for mounting accessories

• Maximum operating speed: up to 35 000 rpm

• Pack quantity: 3 pieces

• Compatibility: Dremel-type rotary tools and multi-tools with 3.2 mm chuck

Main features:

• Ergonomic mounting: threaded head that allows accessories such as felt wheels and polishing bits to be screwed on directly.

• Ease of use: robust and intuitive design for a quick accessory change.

• Versatility: used mainly with accessories intended for polishing and finishing.

Technical applications:

• Securing felt polishing wheels (e.g. models 414, 422, 429) for bright finishes on metals and plastics.

• Mounting polishing bits for surface finishing and precision in detail work.

The Dremel 537 accessory is a brass brush for rotary tools designed for cleaning and surface finishing of relatively soft and delicate metals, ideal for removing oxidation and residues and for creating a satin or matt finish without scratching the surface. The brass bristles are non‑sparking and softer than steel, reducing the risk of damaging sensitive materials.

Technical data:

• Type: brass brush for cleaning/polishing

• Model: 537

• Shank diameter: 3.2 mm

• Working diameter: 3.2 mm

• Bristle material: brass (wire brass)

• Shape: rotary brush

• Accessory length: approx. 48 mm

• Maximum operating speed: 15 000 rpm

• Compatibility: rotary tools with 3.2 mm shank (Dremel and compatible)

Technical applications:

• Cleaning of soft metal surfaces such as gold, bronze, copper and brass without generating sparks

• Surface finishing to achieve a satin or matt effect

• Removal of oxidation and residues from joints or hard-to-reach points

• Surface preparation before further machining or fine polishing

The Dremel TR 562 is a cutting accessory specific to Dremel TRIO tools, designed to make cuts in ceramic wall tiles, plasterboard and cement boards with precision and control. It is suitable only for use with the Dremel TRIO system and is not compatible with standard rotary multi-tools.

Technical data:

• Type: cutting bit for wall tiles/panels

• Model: TR 562

• Fitting: 4.8 mm shank (compatible with Dremel TRIO system)

• Working diameter: 3.2 mm

• Accessory length: approx. 52 mm (overall size)

Applications: cutting of ceramic wall tiles, plasterboard and cement boards; suitable for shaping and fitting around sockets, profiles or pipework during installations and renovations.

The Dremel 431 is a set of replacement abrasive sanding bands for rotary tools, designed for sanding, shaping and removing material on a variety of surfaces. These 60 grit bands provide a medium-coarse abrasive action, suitable for finishing and surface preparation before further work.

Technical data:

• Type: abrasive bands / cylinders for sanding and shaping

• Model: Item 431

• Working diameter: 6.4 mm

• Abrasive grit: 60 (medium-coarse)

• Shank diameter: 3.2 mm (standard for rotary tools)

• Accessory length: approx. 13 mm

• Band width: ~9 mm

• Material: aluminium oxide abrasive

• Maximum operating speed: up to 35 000 rpm

• Pack quantity: typically a set of 6 bands

• Compatibility: used with mandrel 430 or equivalent for abrasive bands on rotary tools

Technical applications:

• Sands and shapes wood, plywood and composite panels

• Removal of rust and oxidation from metal surfaces

• Shaping of rubber, plastic and fibreglass surfaces

• Surface preparation before painting or further finishing

The Dremel 8193 is an aluminium oxide grinding stone for rotary tools, designed for grinding, deburring and general sharpening operations on a wide range of metallic materials. The cylindrical shape allows it to work effectively on tapered and irregular surfaces, making it suitable for the needs of workshops, DIY and mechanical / detail work.

Technical data:

• Type: aluminium oxide grinding stone for grinding and deburring

• Model: 8193

• Working diameter: 15.9 mm

• Shank diameter: 3.2 mm (1/8 in)

• Shape: cylindrical

• Abrasive material: aluminium oxide

• Accessory length: approx. 38 mm

• Recommended maximum operating speed: up to 35 000 rpm (indicative)

• Compatibility: rotary tools with an accessory chuck of 3.2 mm

Technical applications:

• Grinding and deburring on metal and ferrous materials

• Sharpening of cutting tools such as blades, chisels and drill bits

• Smoothing of welded joints, removal of rivets and rust

• Preparation and finishing of tapered or irregular surfaces
