DREMEL ACCESSORY ART.536

The Dremel 7105 is a spherical diamond bit for rotary tools, designed for engraving, sculpting, shaping and material removal on hard or abrasive surfaces. This accessory has a coating of diamond particles that increase its resistance and effectiveness on materials that are difficult to work.

Technical data:

• Type: diamond bit for engraving / carving on hard materials

• Model: 7105

• Shank diameter: 3.2 mm

• Working diameter: 4.4 mm

• Accessory length: approx. 46 mm

• Material: steel with diamond coating for greater hardness and durability

• Shape: spherical bit / diamond disc

• Recommended operating speed: up to approx. 25 000–35 000 rpm (do not exceed the maximum values indicated)

• Compatibility: Dremel rotary tools and multi-tools compatible with a 3.2 mm chuck; does not require an additional chuck

Technical applications:

• Fine engraving and carving on glass, ceramic, porcelain, semi-precious stones

• Shaping and material removal on hardened and hard metals

• Detailed work on wood and other materials that are difficult to work with standard tools

Dremel Pack of 3 engraving cutters – item 110 is an engraving cutter/cutting engraving bit with a cylindrical head of approx. 1.9 mm, designed for detail work with high-speed rotary tools. It is suitable for shaping, engraving, grooving and material removal on various materials, offering precision even on curved surfaces.

Technical data:

• Type: engraving cutter / engraving bit

• Model: 110 / 26150110JA

• Working diameter: ~1.9 mm (5/64 in)

• Shank diameter: 3.2 mm (1/8″)

• Accessory length: ~45 mm

• Material: high-speed steel

• Maximum recommended operating speed: up to approx. 35 000 rpm

• Compatibility: Dremel rotary tools and multi-tools with a 3.2 mm chuck

Pack quantity:

• 1 engraving cutter

Technical applications:

• Engraving and material removal on wood, plastic, laminates, soft metals and similar materials

• Creation of grooves, profiles, hollowing and precision details

• Can also be used on curved or hard-to-reach surfaces

The Dremel 401 is a mandrel (screw pin) for rotary tools, designed for mounting and securing polishing and cleaning accessories on Dremel multi-tools. It is particularly suitable for use with felt wheels and other accessories intended for finishing.

Technical data:

• Type: mandrel / accessory mounting pin

• Model: 401

• Shank diameter: 3.2 mm (≈ 1⁄8″) standard for rotary tools

• Total length: approx. 39 mm

• Material: wear-resistant metal

• Shape: screw pin with threaded head for mounting accessories

• Maximum operating speed: up to 35 000 rpm

• Pack quantity: 3 pieces

• Compatibility: Dremel-type rotary tools and multi-tools with 3.2 mm chuck

Main features:

• Ergonomic mounting: threaded head that allows accessories such as felt wheels and polishing bits to be screwed on directly.

• Ease of use: robust and intuitive design for a quick accessory change.

• Versatility: used mainly with accessories intended for polishing and finishing.

Technical applications:

• Securing felt polishing wheels (e.g. models 414, 422, 429) for bright finishes on metals and plastics.

• Mounting polishing bits for surface finishing and precision in detail work.

The Dremel Art. 636 is a drill bit set specifically for wood, designed for precision drilling in wood and similar materials with compatible rotary tools. Each bit features a centring point for a precise, straight start to the hole and a titanium coating for longer life and consistent performance.

Technical data:

• Type: wood drill bit set for rotary tools

• Model: 636

• Number of bits included: 4 pieces

• Working diameters: 3 mm, 4 mm, 5 mm, 6 mm

• Shank diameter: 3.2 mm (1/8″)

• Coating: titanium for long service life

• Centring point: yes, for accurate holes and a straight entry

• Recommended use: drilling in softwood, hardwood, laminate, plywood, chipboard and fibreboard

• Maximum recommended operating speed: up to 35 000 rpm

• Typical applications: precision drilling in wood, making holes from Ø 3 mm to Ø 6 mm, preparing joints, screw pilot holes and craft details

The Dremel 615 is a high-speed steel (HSS) router bit designed for compatible rotary tools, intended for rounding edges and chamfering corners on wood or similar materials. This accessory is ideal for decorative work, profile finishing and detail cuts on wood and soft materials.

Technical data:

• Type: router bit / bit for rounding corners on wood and soft materials

• Model: Item 615

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm

• Total accessory length: approx. 37 mm

• Material: high-speed steel (HSS)

• Recommended maximum operating speed: up to 35 000 rpm

• Guide pin: present, for stability and cutting precision

• Tool compatibility: Dremel rotary multi-tools with a 3.2 mm chuck or router attachment (e.g. 231 or 335)

Technical applications:

• Rounding and chamfering of edges and corners on wood

• Decorative cuts and finishing on panels and edges

• Detail work on soft materials such as wood, plywood, laminates, plastic and perspex

The Dremel 439 is a replacement abrasive cylinder for rotary tools, used in combination with the mandrel and abrasive band to sand, shape and finish various types of surface. The medium grit makes it suitable for material removal and shaping on wood, metal, fibreglass, rubber and other similar materials.

Technical data:

• Type: abrasive cylinder for sanding/shaping

• Model: Item 439

• Working diameter: 9.5 mm

• Shank diameter: 3.2 mm (standard for rotary tools)

• Abrasive grit: approx. 60 (medium)

• Material: abrasive on rotating cylinder

• Shape: abrasive cylinder

• Compatibility: Dremel rotary tools and multi-tools with 3.2 mm mandrel

Technical applications:

• Sanding and material removal on wood, plywood and fibreglass

• Removal of rust or light oxidation from metal surfaces

• Shaping of profiles and surfaces on materials such as rubber and plastic

• Surface preparation before finishing or painting

The Dremel 8215 is an aluminium oxide grinding stone designed for grinding, deburring and sharpening on metals and other hard surfaces. The cylindrical shape and large diameter make this accessory suitable for general work, burr removal, smoothing welded joints and finishing on tapered or flat surfaces.

Technical data:

• Type: aluminium oxide grinding stone for general grinding, deburring and sharpening

• Model: 8215

• Working diameter: 25.4 mm

• Shank diameter: 3.2 mm

• Accessory length: approx. 40 mm

• Abrasive material: aluminium oxide

• Shape: cylindrical

• Recommended maximum operating speed: up to approx. 20 000 rpm (varies depending on the material)

• Compatibility: rotary tools fitted with a chuck for 3.2 mm accessories (Dremel series and compatible tools)

Technical applications: smoothing, deburring and sharpening of metals, removal of burrs from castings, smoothing welded joints, removal of rivets and rust.

The Dremel 640 is a high-speed steel (HSS) router bit of 6.4 mm designed for rotary tools, ideal for V-grooves, decorative engraving and carving, especially in light or soft materials such as wood, plywood, laminates and plastic. It is also particularly suitable for decoration and finishing details and can be used with dedicated router/plunge accessories to optimise the depth of cut.

Technical data:

• Type: router bit for V-grooves in wood and soft materials

• Model: Art. 640

• Working diameter: 6.4 mm

• Shank diameter: 3.2 mm (compatible with standard chucks)

• Accessory length: approx. 37 mm

• Effective working length: approx. 2.0 mm

• Material: high-speed steel (HSS)

• Recommended operating speed: up to 35 000 rpm

• Compatibility: rotary multi-tools with 3.2 mm chuck, including use with the Dremel router/plunge attachment for greater depth control.

Technical applications:

• Cutting V-grooves in wood and similar materials

• Engraving shapes, lettering or decorative profiles

• Inlay work and finishing on panels and composite surfaces

The Dremel 431 is a set of replacement abrasive sanding bands for rotary tools, designed for sanding, shaping and removing material on a variety of surfaces. These 60 grit bands provide a medium-coarse abrasive action, suitable for finishing and surface preparation before further work.

Technical data:

• Type: abrasive bands / cylinders for sanding and shaping

• Model: Item 431

• Working diameter: 6.4 mm

• Abrasive grit: 60 (medium-coarse)

• Shank diameter: 3.2 mm (standard for rotary tools)

• Accessory length: approx. 13 mm

• Band width: ~9 mm

• Material: aluminium oxide abrasive

• Maximum operating speed: up to 35 000 rpm

• Pack quantity: typically a set of 6 bands

• Compatibility: used with mandrel 430 or equivalent for abrasive bands on rotary tools

Technical applications:

• Sands and shapes wood, plywood and composite panels

• Removal of rust and oxidation from metal surfaces

• Shaping of rubber, plastic and fibreglass surfaces

• Surface preparation before painting or further finishing

The item 1453 is a complete sharpening kit for saws and chains, designed to keep blades and chains efficient and performing at their best. Ideal for precise and safe cutting, it extends chain life and ensures smooth, controlled cutting operations.

Technical data:

• Type: sharpening kit for saws and chains

• Model: 1453 / 261501453JA

• Compatibility: chainsaw chains of various brands

• Kit contents: round file, sharpening guide, positioning supports

• Material: hardened steel for files, tough plastic for supports

• Recommended use: regular chain maintenance for precise and safe cuts

Quantity in the pack:

• 1 × complete sharpening kit

Technical applications:

• Sharpening and maintenance of chainsaw chains

• Restoring the edge for clean, even cuts

• Preventive maintenance operations to extend chain life

The Spare nozzle kit for Dremel VersaTip includes replacement soldering tips for gas tools of the VersaTip and VersaFlame series. This set is designed to restore soldering function when the original nozzles are worn or blocked and helps maintain adequate thermal performance in gas brazing and soldering tools.

Technical data:

• Type: kit of replacement soldering tips/nozzles

• Tool compatibility: Dremel VersaTip 2000 / VersaFlame 2200 (gas soldering irons) and equivalent models that use interchangeable soldering tips

• Material: heat-resistant metal (steel or specific soldering alloy)

• Applications: soldering of components, joints and fine metal details

• Pack quantity: 4 replacement nozzles/tips

• Use: replacement of worn or blocked original nozzles, restoring soldering precision

Main features:

• Standard-shape soldering tip/cone for VersaTip gas tools;

• Design compatible with the tool's original fitting systems;

• Helps maintain soldering efficiency and quality even after the original nozzles have worn.

The Dremel 7134 is a flat-head diamond bit for rotary tools, designed for engraving, carving, precision cutting, finishing and touching up hard and compact materials. The accessory is coated with diamond particles that ensure a high material removal rate and a long service life, ideal for detail work on surfaces that are difficult to machine.

Technical data:

• Type: diamond bit for detailed engraving/cutting/carving

• Model: 7134

• Working diameter: 2.0 mm

• Shank diameter: 3.2 mm

• Total length: approx. 46 mm

• Bit shape: thin flat head for precise engraving

• Material: steel with diamond coating

• Maximum recommended speed: 25 000 rpm

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm accessory chuck

Technical applications:

• Detail engraving on glass, ceramic and stone

• Carving and touching up hardened metal and hard steel

• Cutting and finishing on wood, plastic and composite materials

• Precision work on small and intricate surfaces

The TR 615 cutter is an accessory for Dremel TRIO tools designed specifically for rounding and shaping corners and edges on soft materials such as wood, plastic, rubber and Plexiglas. The tool produces rounded profiles and softer finishes on surfaces of small craft projects and detail work.

Technical data:

• Type: edge-rounding cutter

• Model: TR 615

• Working diameter: 9.5 mm

• Shank diameter: 4.8 mm

• Recommended materials: hardwood, softwood, rubber, plastic, Plexiglas, carbon

• Compatibility: dedicated accessory for Dremel TRIO (not suitable for traditional multi-tools without a TRIO adapter)

• Shape: rounded profile for chamfering and finishing corners

Main details:

• Type: pair of replacement brushes for Dremel rotary tool

• Item code: 0615298790 / UEB0615298790

• Application: replacement motor component for Dremel tools

• Dimensions: approx. 5 × 5.5 mm

• Function: replacement of worn brushes to restore motor performance

The Dremel 530 accessory is a circular brush with stainless steel bristles for rotary multi-tools, designed for cleaning, deburring and surface polishing on corrosion-sensitive or delicate materials. The stainless steel bristles reduce the risk of oxidation after treatment and are also effective on flat surfaces and in hard-to-reach places.

Technical data:

• Type: circular stainless steel brush for rotary tools

• Model: 530

• Working diameter: 19.0 mm

• Shank diameter: 3.2 mm (1/8″)

• Overall length: approx. 44 mm

• Bristle material: stainless steel

• Shape: circular radial brush

• Recommended maximum operating speed: up to 15 000 rpm

• Compatibility: rotary tools with 3.2 mm chuck

Technical applications:

• Cleaning and removal of oxidation from stainless steel, aluminium and non-ferrous metals

• Deburring of edges and joints on metal surfaces

• Surface finishing of silver, brass and copper parts

• Surface preparation before painting or further treatments

The Dremel 7120 is an oval disc diamond abrasive bit designed for Dremel-type rotary tools, specifically for engraving, shaping and removing material on hard or fragile surfaces. It is particularly suitable when precision work is needed on resistant materials such as glass, ceramic or hardened metal, where a traditional cutter would perform less well or wear out quickly.

Technical data:

• Accessory type: diamond bit / abrasive disc for finely detailed engraving and shaping

• Model: 7120

• Working diameter: approx. 6.7 mm

• Shank diameter: 2.4 mm (3/32″) standard Dremel

• Shape: oval diamond disc

• Material: steel with diamond coating

• Maximum recommended speed: up to 25 000 rpm (in some references up to 35 000 rpm)

• Compatibility: Dremel rotary tools and other multi-tools with a 3.2 mm accessory chuck

Technical applications:

• Engraving and shaping of hard surfaces such as glass, ceramic, porcelain

• Detail work on hardened metal and hard steels

• Precision work on thin materials or materials that are difficult to section

• Material removal with greater control than conventional abrasives
